TX-RZ900/TX-RZ800

AV RECEIVER

Basic Manual

The Basic Manual includes information needed when starting up

and also instructions for frequently used operations. The Advanced

Manual has more detailed information and advanced settings.

CONTENTS

Front Panel .......................................................................3

Display .............................................................................. 4

Rear Panel........................................................................5

Step 1: Connections ............................................6

1 Connecting speakers.....................................................6

･ Speaker layout ...........................................................6

･ Height speaker types .................................................7

･ Instructions on how to connect speakers ...................8

2 Connecting the TV and players .....................................9

･ HDMI cable connection ..............................................9

･ Connecting Components without HDMI ...................10

3 Other connections .......................................................11

Step 2: Initial Setup ...........................................12

1 AccuEQ Room Calibration ..........................................12

2 Source Connection ...................................................... 13

3 Remote Mode Setup ...................................................14

4 Network Connection ....................................................14

Step 3: Playing Back .........................................16

1 Basic operations .......................................................... 16

･ Remote controller parts name .................................. 16

2 Network Functions .......................................................17

3 AirPlay

.......................................................................17

4 BLUETOOTH

function ...............................................18

5 AM/FM Radio ..............................................................18

6 Multi-zone .................................................................... 19

･ Making Multi-zone Connection ................................. 19

･ Performing Multi-zone Playback ..............................20

7 Quick Setup menu ....................................................... 21

8 Other useful functions .................................................22

Troubleshooting ..............................................................23

Specifications .................................................................24

Table of display resolutions ............................................25

Resolutions supported by HDMI ..................................... 25

Supplied Accessories .......................................Back cover

En-2

Features

TX-RZ900/TX-RZ800:

･ Equipped with 7 ch amplifier

･ Supports playback in Dolby Atmos format and has Dolby

Surround listening mode

･ Supports playback in DTS:X format and has DTS

Neural:X listening mode

･ THX Select2 Plus certified

･ Equipped with 4K compatible HDMI IN/OUT jacks

･ Equipped with 2 HDMI output jacks

･ Supports the HDMI Standby Through function which

allows transmission from players to the TV in standby

state

･ Supports HDCP2.2 (supported by HDMI IN1 to IN5/

HDMI OUT MAIN/SUB)

･ Supports ARC (Audio Return Channel)

･ Supports variety of network functions such as Internet

Radio, DLNA, AirPlay, etc.

･ Supports Wi-Fi and BLUETOOTH

･ Bi-Amping capability

･ A/V Sync Function to correct deviation of audio and

video

･ Multi-zone function (Zone 2 and Zone 3) which allows

you to play something in the main room while enjoying

a different source in a separate room (Video and audio

can also be output to Zone 2 through HDMI)

･ Music Optimizer™ for compressed digital music files

･ Phase Matching Bass System

･ Automatic speaker setup available using supplied

calibrated microphone (AccuEQ Room Calibration)

･ Supports playback of MP3, WMA, WMA Lossless,

FLAC, WAV, Ogg Vorbis, Apple Lossless, DSD, Dolby

TrueHD via network and USB storage device (the

supported formats will differ depending on the use

environment)

TX-RZ900:

･ The two front channels have parallel push-pull circuits

for reproducing powerful bass

･ Equipped with a high-class toroidal transformer as an

independent power source for the audio circuitry

Produktspecifikationer

Varumärke:	Onkyo
Kategori:	mottagare
Modell:	TZ-RZ800
Vikt:	17000 g
Bredd:	435 mm
Djup:	433.5 mm
Höjd:	201.5 mm
Förpackningens bredd:	582 mm
Wi-Fi:	Ja
Frekvensband:	AM, FM
Ljudutgångskanaler:	7.2 kanaler
Internetradio:	Ja
Fjärrkontroll ingår:	Ja
Ingångskänslighet:	300 mV
AirPlay:	Ja
Pre-out anslutning:	Ja
THX-certifierad:	THX Select2 Plus
Produktens färg:	Svart
Antal USB-portar:	1
Låddjup:	521 mm
Vikt inkl. förpackning:	20500 g
Inbyggd kortläsare:	Nej
Kompositvideo ut:	1
Strömförbrukning (vanlig):	90 W
AC-inspänning:	220-240 V
3D kompatibilitet:	Nej
Nätverksansluten (Ethernet):	Ja
Effekt per kanal (20-20KHz @ 8 ohm):	185 W
Mottagartyp:	Surround
Optisk enhet ingår:	Nej
Apple-kompatibel dockningsmöjlighet:	Stöds inte
Växelström Frekvens:	50 - 60 hz
RS-232-gränssnitt:	Ja
Strömförbrukning i vänteläge:	0.2 W
Bluetooth:	Ja
Ingående kompositvideo:	3
Komponentvideo in (YPbPr / YCbCr):	2
Komponentvideo (YPbPr / YCbCr) ut:	1
Ljudingång (vänster och höger):	9
Antalet förinställda stationer:	40
Internetradio tjänster som stöds:	Spotify
Digital audio optisk, ingående:	3
Digital koaxialingång för ljud:	2
FM band:	87.5 - 108 MHz
AM band:	530 - 1710 kHz
HDMI-in:	8
Dynamisk effekt per kanal (8 ohm):	150 W
Dynamisk effekt per kanal (4 Ohm):	250 W
Dämpfaktor:	40
Dynamisk effekt per kanal (3 ohm):	300 W
