Sida 1/8
Manual Contents
__________________________________________
Manual Contents 1-0
Welcome! Product Description 1-1
System Requirements for Setup 1-2
Installation 1-3
Troubleshooting, Maintenance, Technical Support 1-5
Product Specifications 1-6
Warranty Information 1-8
Warning 1-9
Regulatory Statements 1-10
Pictorials
Figure 1 – Optical DVI Extension Module System 1-1
Figure 2 – Auto EDID button 1-3
Figure 3 – Connection of optical fiber 1-4
1-0 Manual Contents
User Manual
M1-201SA-TR
Doc No. : OE-D210222-201SA / Rev3.2
Four (4) Fiber Detachable
DVI Module
Welcome!
Congratulations on your purchase of the Stretch DVI
TM
M1-201SA-TR Optical
DVI (Digital Visual Interface) Extension Module. This manual contains
information that will assist you in installing and operating the product.
Product Description
The M1-201SA-TR optical DVI module transmits four (4) optical data, Red,
Green, Blue and clock and can be extended up to 500 meters (1,640ft) over a
pair of LC duplex multi-mode fibers or four (4) LC simplex multi-mode fibers at
WUXGA (1920x1200) at 60Hz vertical refresh.
The EDID (Extended Display Identification Data) in a display can be read and
restored by just plugging once transmitter to the display. This Auto EDID
programming feature makes the installation of M1-201SA more easy and
flexile at any variable resolution display systems.
For your convenience, UXGA EDID would have been done before shipment
as a default.
Shipping Group
M1-201SA-TR Optical DVI Extension Module: One (1) pair
DC power adapter: Two (2) units
User Manual
Figure 1 – Optical DVI Extension Modules System
1-1 Welcome, Product Description
System Requirements for Setup
Hardware requirements
You must have a DVI graphic controller or card having a DVI port
in your PC, SUN or Mac systems. It should support the maximum
graphic resolution feature of displays to be connected.
No special requirements for memory size, CPU speed and
chipsets, if you’ve already properly installed your DVI graphic
controllers or cards.
Software requirements
No special restrictions, if you’ve already properly installed your
DVI graphic controller in your OS.
AC/DC Power Adapter Technical Advisory
The transmitter (Tx) module of M1-201SA-TR provides DVI pin that
offers power protection circuit against the conflict of power supply
between the external DC power adapter and your graphic card. It
offers an auto switching function of whether to use an AC/DC power
adapter or not, depending on power supply capability of the graphic
card through the +5V pin, you are using.
However, the receiver (Rx) module should be used with an AC/DC
power adapter.
Tips: In general, most of laptops or desktop PCs with PCI Express graphic
card require AC/DC power adapter for the transmitter module.
Note:
Recommended to use power supply adapters offered by Opticis,
which has short-circuited break features.
1-2 System Requirements for Setup
