INSTRUCTIONS FOR USE
Pro-Ject Stereo Box RS
© Pro-Ject Audio Systems Stereo Box RS · Revision 2014.2.2 ·
2
Dear music lover,
thank you for purchasing a PRO-JECT AUDIO amplifier.
In order to achieve maximum performance and reliability you should study these instructions for use carefully.
!
Warning of a hazard for the user, the unit or possible misuse
Important notice
Safety instructions
!
AC outlet voltages vary from country to country. Before connecting to the mains, make sure that the
voltage in your area meets the voltage requirements printed on the power supply.
The power supply is used to disconnect the unit from the mains. Make sure that the power supply is easily
accessible at all times. Never handle the device, the power supply while your hands are wet or damp.
Avoid letting liquids enter the device or the power supply. Never place any item containing liquid,
such as a flower vase on or near the device. Never spill any liquid on the device or the power supply.
Never place any naked flame sources, such as lighted candles on or near the device. The product shall not
be used in damp or wet locations, next to a bathtub, sink, swimming pool or any other similar conditions.
Tubes produce heat. Proper ventilation has to be guaranteed all the time. The unit must not be stacked.
Connecto rs
PUSHPUSH
!
Make all connections whilst the amplifier is disconnected from the power supply.
Take care to connect the left and right channels correctly. The right channel is usually marked red,
the left channel black or white.
The red speaker terminals carry the positive signal (+), the black speaker terminals the negative
signal ( ). Make sure the polarity of the connection is correct at each end of the cables. –
Only connect one loudspeaker with an impedance not less than 4 ohms per channel.
Wiring XLR sockets : 1 ground, 2 “hot” and 3 “cold”.
Never use any other power supply than the one supplied with the unit.
Inputs
Line level sources such as a CD player or a tuner can be connected to the input sockets marked - .
IN
IN
IN
IN IN 1
1
1
11 IN 6
IN 6
IN 6
IN 6IN 6
Subwoofer output
An active subwoofer may be connected to the output sockets marked .
Sub
Sub
Sub
SubSub
Pre Out
A power amplifier or active loudspeakers can be connected to the output sockets marked .
Out Variable
Out Variable
Out Variable
Out VariableOut Variable
© Pro-Ject Audio Systems Stereo Box RS · Revision 2014.2.2·
3
Record output, connecting a headphone amplifier
Out Fix
Out Fix
Out Fix
Out FixOut Fix connects an analogue record device ore a Pro-Ject Head Box headphone amplifier.
Out Fix
Out Fix
Out Fix
Out Fix Out Fix provides a fixed output level.
Mains power connection
Connect the low voltage plug from the power supply to the 2x48
2x48
2x48
2x482x48V=
V=
V=
V=V= socket of the amplifier before
connecting the power supply to the mains.
Remote cont rol
CH+
CH-
VOL+
VOL-
ON/OFF
ON/OFF
turns the unit on or back into standby
VOL
and
+
VOL
adjust the sound volume
CH
and
+
CH
select the inputs
Front panel controls
Stereo Box RS
To switch on from standby or to standby
The switch on the left hand side of the front panel turns the unit on or back into standby. The blue LED above
the stand-by switch shows that the unit is switched on.
!
After switching on, the tubes need a short time to reach the correct operating temperature. During
warm up the blue LED above the stand-by switch is blinking.
We recommend to set the volume control to 0, prior to switching on.
Input selector
After the unit is powered on, operating the switch next to the six LEDs selects the inputs. The selected input
will be shown by the corresponding LED.
Volume
Adjust the volume to the desired level, using the large knob on the front panel.
