INSTRUCTIONS FOR USE

Pro-Ject Receiver Box

Dear music lover,

thank you for purchasing a PRO-JECT AUDIO receiver.

In order to achieve maximum performance and reliability you should study these instructions for use carefully.

Warning of a hazard for the user, the unit or possible misuse.

Important notice.

Help to protect the environment

If you are not going to use the receiver for an extended period of time, e.g. vacation, we suggest to

disconnect it from the AC mains. Please be certain that the receiver is in standby-mode prior to unplugging

the power supply from the AC mains.

Connectors

FM Ant.

75 Ohm

IN 1

IN 2

Make all connections whilst the receiver is disconnected from the power supply.

Take care to connect the left and right channels correctly. The right channel is usually marked red,

the left channel black or white.

Inputs

Line level sources such as CD player, TV-set or MP3-player can be connected to the input sockets marked IN 1

or IN 2.

Antenna input

Connects any antenna cable with a co-axial DIN-plug / US-model F-plug.

Connection to the speakers

The output terminals accept loudspeaker cables terminated with 4mm ∅ Banana plugs, spades connectors

or naked wire.

Only connect one loudspeaker with an impedance not less than 4 Ohm per channel.

Mains power connection

The unit is supplied with a power supply suitable for your country's mains supply. Check the label before

connecting to ensure compliance with the mains rating in your house. Connect the low voltage plug from the

power supply to the Power 20V



socket before connecting the power supply to the mains.

Remote control

ON/OFF

INPUT

TUNE

VOL-

VOL+

CH+

CH-

Stand-By

ON/OFF

short press turns the unit on, long press takes it back into standby.

Powered on, a short press activates and deactivates mute

Volume

VOL

and

VOL

adjust the sound volume

Selecting an input

INPUT

selects the inputs

Selecting the tuning mode

Pressing (min. 3 seconds)

selects the tuning modes manual program

search (MANUAL) and automatic program search (AUTO) in turns.

Manual program search - the display shows MANUAL

TUNE

decreases,

TUNE

increases the reception frequency in 50kHz steps.

Automatic program search - the display shows AUTO

CH-

starts the automatic frequency scan downwards,

CH+

starts the scan upwards.

Program selection from memory - the display shows MEMORY

activate the memory function. Pressing

access the presets 1 - 8 directly.

CH-

and

CH+

select -memory function has to be activated- the memory positions 9 - 99.

Saving a program in the memory list

Tune to the frequency to be stored. Press

twice in rapid succession. The display will show STORE.

CH+

will select the next memory position up the list,

CH-

selects the next memory position down the list.

The memory positions 1 - 8 can be selected directly by pressing

Press once again

to store the program at that position. The display shows STORED.

Saving a program to a particular memory position overwrites any program already stored at that

position. The memory retains its contents through a power off/on cycle.

Produktspecifikationer

Varumärke:	Pro-Ject
Kategori:	mottagare
Modell:	Receiver Box
Vikt:	670 g
Känslighet:	17 dB
Total harmonisk distorsion (THD):	0.05 %
Fjärrkontroll ingår:	Ja
Produktens färg:	Silver
bruksanvisning:	Ja
Produktstorlek (BxDxH):	103 x 122 x 36 mm
Frekvensområde:	20 - 20000 hz
Externa anslutningar:	RCA
FM band:	87.5 - 108.5 MHz
Beskrivning av uteffekt:	2 x 20/30W
