KEEP THESE INSTRUCTIONS
Page 1 of 6
SPEC. NO. 93045757 1-15-16
P8044, P8061, P8066, P8071, P8080,
P8161, P8171, P8175 & P8180 SERIES
Assembly & Installation Instructions
CAUTION:
Read instructions carefully and turn electricity off at main circuit breaker panel before beginning
installation.
WARNING: Follow the instructions carefully to assure full compliance with local, state, and NEC requirements. If there are any
questions, contact a Qualified Electrical Contractor.
WARNING: Risk of fire or electrical shock. Install this kit only in the Recessed Cans matching the dimensions listed below.
WARNING:To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects.
CAUTION: Risk of fire. Consult a Qualified Electrician to ensure correct branch circuit conductor.
NOTE:This product is designed to operate with most standard incandescent or low voltage electronic dimmer switches. Results
may vary. For recommended dimmers, consult product specification sheet for more details.
NOTE: SUITABLE FOR WET LOCATIONS IN COVERED CEILINGS
WARNING:This product contains chemicals known to the State of California to cause cancer, birth defects and/or other
reproductive harm. Thoroughly wash hands after installing, handling, cleaning, or otherwise touching this product.
NOTE: Always install with ambient temperatures specified on the product specification sheet. 5 year warranty.
See www.progresslighting.com for details.
Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation.
THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE INSTALLATION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
1
"A"
"B"
RETROFIT
DEDICATED LEDHOUSING
FORTITLE 24
1
2
1
3
5
5
DEDICATED LED HOUSING
FOR TITLE 24
“A”
RETROFIT
“B”
1
2
3
5
5
1
4
P8071, P8066, & P8171 fit into Progress 6" recessed cans including: P87, P187, P821, P86, & P186 SERIES.
P8061, P8175, & P8161 fit into Progress 5" recessed cans including: P85, P185, P84, & P184 SERIES.
P8080, P8044, & P8180 fit into Progress 4" recessed cans including: P830, P831, & P832 SERIES.
These fit into most competitive recessed cans with “A” and “B” dimensions above. See www.progresslighting.com for more details.
IMPORTANT! Prior to retrofit installation, recessed can must be properly installed and flush with the ceiling. It may be necessary to detach
the socket from a mounting bracket or spring. Remove and discard bracket to allow adequate clearance.
TWIST TRIM ASSEMBLY
COUNTERCLOCKWISE
1/4 TURN WHILE PUSHING
TRIM INTO CAN.
P8071 Series:
“A” = 6-5/16" MIN; 7-1/8" MAX; “B” = 5-1/2" MIN.
P8061 Series:
“A” = 5-5/16" MIN; 6-1/8" MAX; “B” = 5-1/2" MIN.
P8080 Series:
“A” = 4-5/16" MIN; 5-1/8" MAX; “B” = 5-1/2" MIN.
