PackageContents
1of3
ForStyleKAN440EK
Pleasegotoforproductcleaningtips.Gototheselection.
(4)B10CandelabraBaseBulbs60WMaximum,CandelabraBaseT8VintageBulbsarerecommended,bulbsnotincluded.
MinimumHangingHeightis13”,MaximumHangingHeightis49”.
20-30minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtoensureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactyouroriginalplaceofpurchase.
www.quoizel.comCare+Maintenance
LightSource:
FixtureHangingHeight:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
InstallationGuide#IS-KAN440EK
2019QuoizelInc.
ReleasedDate:2019-02-28
visituson-lineatwww.quoizel.com
E
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.
GlassShade
x4
F
FixtureBody
x1
A
Crossbar
Assembly
x1
C
D
6”LRod
x4
12”LRod
x4
B
CeilingCanopy
x1
Figure1
STEP1InstallingtheCrossbarAssembly-
A.PassthesupplywiresthroughtheCrossbarAssembly(A).Attach
theCrossbarAssembly(A)totheoutletboxwiththeheadofthe
greengroundscrewfacingyou.SecuretheCrossbarAssembly(A)
withoutletboxscrews(notincluded).Tightenuntilsnug.
SupplyWires
withGroundWire
OutletBoxScrews
(notincluded)
OutletBox
A
MountingBall
A
HexNutand
LockWasher
MountingScrew
STEP2-TestFittheCeilingCanopytotheCrossbarAssembly
A.RemovethemountingballsfromtheCrossbarAssembly(A).
PlacetheCeilingCanopy(B)ontotheCrossbarAssembly(A)and
securewithmountingballs.Note:TheCeilingCanopy(B)should
besnugagainsttheceilingandheldtightwiththemountingballs.
Ifitisnot,adjustthelengthofthemountingscrewsonthe
CrossbarAssembly(A)byunscrewingthepreassembledhexnut
andlockwasherandthenscrewingthemountingscrewsinorout
ofthecrossbaruntilthecorrectlengthisachieved.Oncethe
CeilingCanopy(B)issecure,removethemountingballand
CeilingCanopy(B)andproceedtoStep3.
B
Figure2
STEP3SeparateSwivelsfromCeilingCanopy-
A.Byusingpliers,unlockhexnutsinsideoftheCeilingCanopy(B)and
removeswivelsfromtheCeilingCanopy(B).
B
CeilingCanopy
ReinforcedPlate
Washer
HexNut
HexNut
Washer
Lanyard
Swivel
Figure3
