1of2
PackageContents
HardwareContents
BB
DD
Ceiling
Canopy
x1
CC
FixtureChain
x2
QuickLink
x4
FixtureBody
x1
AA
Crossbar
x1
Assembly
STEP1-InstalltheCrossbarAssemblytoOutletBoxandAdjust
thelengthoftheNipple
A.AttachtheCrossbarAssembly(AA)totheOutletBoxwiththehead
oftheGreenGroundScrewfacingyou.SecureitwithOutletBox
Screws(notincluded),tightenuntilsnug
B.Adjustthehexnutandlockwasherundersideofthecrossbartothe
middleofthenipple.
C.RemovetheandHexNutfromtheNipple.Placethe
CeilingCanopyovertheNippleagainsttheceilingtodeterminethe
correctpositionofthenipple.ThreadtheFinialontotheNipple.
AdjustthenippletoallowtheCeilingCanopytorestagainstthe
ceilingwhenheldinplacebythe.
D.RemovetheandtheCeilingCanopy(DD).Tightenthelock
washerandthehexnutagainstthecrossbartosecureinplace.
.
LockBall
LockBall
LockBall
OutletBoxScrew
(notincluded)
HexNutand
LockWasher
OutletBox
GreenGroundScrew
AA
LockBall
Figure1
Nipple
HexNut
B
DD
ForStyleAVY542PK
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.
Pleasegotoforproductcleaningtips.Gototheselection.
(5)B10CandelabraBasebulbs60WMaximum,bulbnotincluded.
MinimumHangingHeightis24.25”,MaximumHangingHeightis73.75”.
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtoensureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.MissingParts?Contactyouroriginalplaceof
purchase.
www.quoizel.comCare+Maintenance
LightSource:
FixtureHangingHeight:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
InstallationGuide#IS-AVY542PK
2018QuoizelInc.
ReleasedDate:2019-02-21
visituson-lineatwww.quoizel.com
STEP2-InstallFixtureChains
A.Thread(A)ontotheNippleonthetopofFixture
Body(B),handtightenuntilsnug.
B.AdjusttheFixtureChain(BB)toyourdesiredlengthbyremoving
thelinksifneeded.
C.WiththeFixtureChain(BB)notattachedtothefixtureloopsand
theceilingloopsundersideoftheCeilingCanopy(DD),pullthe
supplywiresandgroundwirethroughtheFixtureChain(BB)
alternatinglinks.AfterthewiresarethroughtheFixtureChain
(BB),pullthesupplywiresandgroundwirethroughtheCeiling
Canopy(DD).
D.AttachoneendsoftheFixtureChains(BB)tofixtureloopswith
twoQuickLinks(CC)asshown.LiftthefixtureandFixtureChains
(BB)upandattachtheotherendsoftheFixtureChains(BB)onto
theceilingloopsundersideoftheCeilingCanopy(DD)withthe
resttwoQuickLinks(CC).
SuggestedrodsandchainlengthforCeilingheight:
8’ceiling:use20linksofchainsand4quicklinks
9’ceiling:use30linksofchainsand4quicklinks
10’ceiling:use40linksofchainsand4quicklinks
FixtureLoop
CC
SupplyWires
andGroundWire
FixtureLoop
x1
A
BB
CC
DD
B
A
C
Glove
x1
Beforeyoustart,wearGloves(C)tokeepproductstayawayfrom
dirtyduringinstallation.
D
Optional
CandleCover
x5
