1of2
6CORPORATEPARKWAY
GOOSECREEKSC29445
wwwquoizelcom
,.
..
AssemblyInstructionSheet#IS-TNC5006EK
ForStyleTNC5006EK
PackageContents
A
CrossbarAssembly
x1
B
6”Rod
x2
C
12”Rod
x2
D
Ceiling
Canopy
x1
ThankyouforpurchasingaQuoizelproduct.
Needassistancewithpartsorassembly?CallQuoizelcustomerserviceat1-800-645-3184
orvisituson-lineatwww.quoizel.com
2017QuoizelInc.
ReleasedDate:2017-09-19
Shade
x6
STEP1-InstallCeilingCanopy,Rodsand
FixtureBodytogether
A.DeterminetheRods(B/C)tobeassembled
totheFixtureBody(F)accordingtoyour
hangingheight.
B.Passthesupplywiresandgroundwire
throughthechosenrods(B/C)andthe
CeilingCanopy(D).ThreadtheFixture
Body(F),thechosenRods(B/C)andthe
CeilingCanopy(D)together.Handtighten
untilsnug.
SuggestedrodsforCeilingheight:
8’ceiling:use(2)12”rods
9’ceiling:use(2)6”rodsand(2)12”rods
B
B
D
SupplyWires
andGroundWire
C
E
C
Figure1
G
LockScrew
x18
F
Pleasegotoforproductcleaningtips.Gototheselection.
(6)B10CandelabraBaseBulbs60WMaximumor
(6)CandelabraBaseVintageT8bulbsarerecommendedbutnotsupplied.
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.comCare+Maintenance
LightSource:
EstimatedAssemblyTime:
Preparation:
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
WarningsandCautions
Turnoffelectricityatcircuitbreakerormainfuseboxbeforeinstallation.Consultalicensedelectricianifindoubt.
Theseinstructionsareprovidedforyoursafety.Itisveryimportantyoureadthemcompletelybeforeinstallingthefixture.Westrongly
recommendthatalicensed,professionalelectricianperformtheinstallation.
Disconnectfixturefrompowersourcebeforereplacingbulbs.Makesurebulbsaregivensufficienttimetocoolbeforeremoval.
FixtureBody
x1
E
STEP2InstallCrossbarAssembly-
.
A.PassthesupplywiresthroughtheCrossbarAssembly(A).Attach
theCrossbarAssembly(A)totheOutletBoxwiththeheadofthe
GreenGroundScrewfacingyou.SecureitwithOutletBoxScrews
(notincluded).Tightenuntilsnug
Figure2
STEP3TestFittingCeilingCanopytoCrossbarAssembly-
A.
CeilingCanopytothe
CeilingCanopy
ceiling
RemovemountingballsfromtheCrossbarAssembly(A).Fitthe
(D)CrossbarAssembly(A)andsecurewith
mountingballs.Note:The(D)shouldbesnug
againsttheandthemountingballs.Ifnot,adjustthelength
ofthenippleontheCrossbarAssembly(A)byunscrewingthe
preassembledhexnutandlockwasherandthenscrewingthe
mountingscrewsinoroutofthecrossbaruntilthecorrectlengthis
achieved.OncetheCeilingCanopy(D)issecure,removethe
mountingballandCeilingCanopy(D)andproceedtoStep4.
Mounting
Screw
HexNutand
LockWasher
MountingBall
A
D
Figure3
SupplyWireswith
GroundWire
OutletBoxScrews
(notincluded)
OutletBox
A
