1
ENGLISH
The DC/DC Converter 24V/90W allows you to operate the
Stellar device from a 12V or 24VDC power source in a car,
boat, or other vehicle equipped with a suitable battery.
Consult your equipment supplier for more information
about this accessory.
The H4i in heating mode can only be used when the device
is connected to mains supply. The Stellar internal battery
will not charge when powered from a DC power source.
WARNINGS
• Read instructions before use.
• Only use the converter when connecting to a 12V or
24V DC supply.
• Do not connect the Stellar device to a 12V or 24V
DC power source while the power source is being
charged from AC mains.
• Do not attempt to modify the converter. There are no
user-serviceable parts inside the converter.
CAUTIONS
• The converter must only be used with Stellar devices
to ensure proper performance of the device.
• The converter is intended for use on 12V or 24V
negative ground systems (where the negative
terminal of the battery is grounded). Using it on a
12V or 24V positive ground system may damage the
Stellar device and the vehicle’s electrical system.
If you are unsure whether you have a negative
ground system, consult the car, boat or other vehicle
manual.
• Make sure the converter is not covered during use to
avoid overheating the device.
• The converter is not intended for use on an aircraft.
Using the converter via a cigarette lighter
Refer to the illustration 1.
1. Before connecting the converter, ensure the switch (A)
is off.
2. Position the converter on a level surface, with the
ResMed logo facing up.
3. Plug the connector end (B) of the converter into the DC
input socket (C) of the Stellar device.
4. Remove the cigarette lighter from the vehicle socket.
5. Plug the cigarette lighter adaptor plug (D) on the
converter into the vehicle cigarette lighter socket.
6. The light (E) on the converter will glow green when the
connection is made and the switch is on. The Stellar
device should then power on.
The light will flash continuously if the connection is
not made, or if the device is in standby mode or power
DC/DC Converter 24V/90W
User Guide
English | Deutsch | Français | Italiano | Español | Português | Nederlands | Svenska | Dansk | Norsk | Suomi | 简体中文 | 繁體中文 | 日本語
CB
E
AD
1
2
2
save mode when the connection is made. If the battery
is low, the light will turn amber. If the light does not
operate, check that the switch on the cigarette lighter
adaptor plug is on.
Notes:
• Some vehicles require the ignition key to be turned
to the “accessories” position to provide power to the
cigarette lighter socket.
• If you connect the Stellar device to a powered converter,
the converter may power down. To resume power, turn
the converter off and on again via the switch on the
cigarette lighter adaptor plug.
• If the battery AND car, boat or other vehicle are not in
good condition, there may not be enough reserve left
in the battery to start the vehicle after use. The Stellar
device will operate using the internal battery. Remove
the converter.
• ResMed does not recommend frequent use of a
standard vehicle battery to power the Stellar device. A
standard vehicle battery is not optimized for frequent
heavy discharges. Contact ResMed Technical Services
for further information and recommendations.
• If the converter cuts power to the Stellar device when
starting your car, boat or other vehicle, disconnect the
converter from the vehicle, wait a few seconds, and then
reconnect it.
• Do not leave the converter switched on and connected
to the power source when the Stellar device is not in
use, as this may discharge the battery over time. Ensure
the DC converter is switched off when not in use.
• You must have an electrical system in good condition.
Have it checked by an auto electrician if in doubt.
• Contact ResMed or a representative if you need help.
Connecting a converter to a battery via
battery clips
Refer to illustration 2.
An adapter cable is required if you need to connect directly
to the battery terminals (e.g. if the battery is out of the
vehicle).
For more information, see the battery guide available on
www.resmed.com on the Products page under Service
& Support.
Technical specifications
Length (connector to connector): 1.6 m
Fuse rating: F 20A L, 250V (fast blow, low breaking capacity)
Input: 12V/24V
13A/6.5A
Output: 24V
3.75A
Typical power consumption: 70W
Maximum power consumption: 110W
Environmental conditions:
Operating temperature: +5°C to +35°C;
Operating humidity: 10 to 95% non-condensing;
Operating altitude: Sea level to 2,591m;
Air pressure range 1013hPa to 738 hPa;
Storage and transport temperature: -20°C to +60°C;
Storage and transport humidity: 10 to 95% non-condensing.
Electromagnetic compatibility:
Product complies with all applicable electromagnetic compatibility
requirements (EMC) according to IEC60601-1-2, for residential,
commercial and light industry environments.
Ensure that wireless communications devices (such as mobile phones,
wireless home network devices, cordless telephones and their base
stations, and walkie-talkies) are kept at least 3.2 ft (1m) away from the
device.
Information regarding the electromagnetic emissions and immunity of
this ResMed device can be found on www.resmed.com, on the Products
page under Service and Support.
Symbols which may appear on the device
Caution; ClassII equipment;
IP21
Protection against
insertion of fingers and against vertically dripping water;
Direct Current; Manufacturer; European
Authorized Representative;
European RoHS; Serial number;
China pollution control; Fuse;
Environmental Information The DC/DC converter
should be disposed of separately, not as unsorted
municipal waste. To dispose of your device, you should use
appropriate collection, reuse and recycling systems
available in your region. The use of these collection, reuse
and recycling systems is designed to reduce pressure on
natural resources and prevent hazardous substances from
damaging the environment. If you need information on
these disposal systems, please contact your local waste
administration. The crossed-bin symbol invites you to use
these disposal systems. If you require information on
collection and disposal of your ResMed device please
contact your ResMed office, local distributor or go to
www.resmed.com/environment.
Limited warranty
ResMed warrants that your ResMed DC/DC Converter
24V/90W shall be free from defects in material and
workmanship for a period of 12 months from the date
of purchase by the initial consumer. This warranty is not
transferable.
If the product fails under conditions of normal use,
ResMed will repair or replace, at its option, the defective
product or any of its components.
This limited warranty does not cover: a) any damage
caused as a result of improper use, abuse, modification
or alteration of the product; b) repairs carried out by any
service organisation that has not been expressly authorised
by ResMed to perform such repairs; c) any damage or
contamination due to cigarette, pipe, cigar or other smoke;
d) any damage caused by water being spilled on or into the
product.
Warranty is void on product sold, or resold, outside the
region of original purchase.
Warranty claims on defective product must be made by the
initial consumer at the point of purchase.
This warranty is in lieu of all other express or implied
warranties, including any implied warranty of
merchantability or fitness for a particular purpose. Some
regions or states do not allow limitations on how long an
implied warranty lasts, so the above limitation may not
apply to you.
ResMed shall not be responsible for any incidental or
consequential damages claimed to have occurred as
a result of the sale, installation or use of any ResMed
product. Some regions or states do not allow the exclusion
or limitation of incidental or consequential damages, so the
above limitation may not apply to you.
