Sida 1/2
SALUS Controls, Units 8-10,
Northeld Business Park,
Forge Way, Parkgate
Rotherham, S60 1SD
Model: TRV3RF
SUPER-QUIET TRV
SALUS Controls is a member of the Computime Group
Maintaining a policy of continuous product development SALUS
Controls plc reserves the right to change specications, design
and materials of products listed in this brochure without prior notice.
SALUS Controls GmbH,
Dieselstrasse 34,
63165 Mühlheim am Main,
Germany
Quick Guide
Email: tech@salus-tech.com
A
B
H2
H1
M28 (with washer) M28 (without washer) M30
A > 9.5 mm A > 9.5 mm A > 6 mm
5.3 < B < 8 mm 5.3 < B < 8 mm B < 5.1 mm
Ф1 < 21 mm Ф1 < 21 mm Ф1 < 7.2 mm
Ф2 < 7 mm Ф2 < 7 mm Ф2 < 25 mm
Ф3 < 35.5 mm Ф3 < 35.5 mm Ф3 < 36.5 mm
H1 < 12.7 mm H1 < 12 mm H1 ≤ 15.5 mm
H2 > 8.7 mm H2 > 8.0 mm H2 ≥ 11 mm
7.5<H3 < 8 mm H3 < 7.5 mm H3 ≤ 10.2 mm
V06
04/2025
www.saluscontrols.com
MULTI-LANGUAGE
MANUAL
Introduction
Use in accordance to national and EU regulations. Use the device as intended,
keeping it in dry condition. Product for indoor use only. Installation must
be carried out by a qualied person in accordance to national and EU
regulations.
Safety Information
This product complies with the essential requirements and other relevant
provisions of Directives 2014/53/EU and 2015/863/EU. The full text of the
EU Declaration of Conformity is available at the following internet address:
www.saluslegal.com.
2405-2480MHz, <14dBm
Product Compliance
The TRV3RF is compatible with the IT600 series (SQ610, VS10RF, VS20RF,
SQ610RF) and Elypso series. Please note that it functions exclusively with
UG600, UGE600, and UG800 gateways.
The TRV3RF is an advanced, cutting-edge Thermostatic Radiator Valve (TRV)
and the quietest on the market designed for seamless home comfort and
energy eciency, making it ideal for noise-sensitive environments. The
TRV3RF features a sophisticated modulating head, enabling precise control
by gradually opening or closing the valve based on room temperature.
Using an intelligent temperature compensation algorithm, the TRV3RF
dynamically adjusts to environmental factors such as radiator heat,
drafts, or sunlight. This ensures consistent, accurate room temperatures
while optimizing energy eciency. Perfect for modern, energy-conscious
homes, the TRV3RF delivers tranquility, comfort, and sustainability in one
innovative package.
Box Content
TRV3RF
M28
Valve Adapter
M30
Valve Adapter
Danfoss
Valve Adapter
Allen Key
Metallic
Washer
2 x AA
Batteries
2 x
Hex Screws
Device Compatibility
Gateways
UGE600
UG800
Thermostats
VS10RF/VS20RF
Thermostats
SQ610 Range
Thermostats
EL600F
Receivers
RX30RF
Product description
1. Function / Setup Button
2. Dial Ring
3. Digital Display
4. Lock / Unlock Valve Adapter
5. Battery cover
6. Locking pin
Valve compatibility
The TRV3RF includes three adapters designed for compatibility with a wide
range of valves available on the market. Before beginning the installation,
please verify that your existing valves are compatible with the provided
adapters:
• M28 (with or without metallic washer)
• M30 (metallic washer NOT required)
• • DanfossDanfoss valves (metallic washer NOT required)
*For Danfoss valve we can proceed with the provided RA adapter.
1
2
3
4
6
5
FRONT VIEW BACK VIEW
Icons and Display
Battery Level
Key Lock - 10s press
RF Status
O Mode (Frost Protection)
Binding Status
Schedule Mode
Temperature and Other Information for
Vertical Positioning of TRV
Temperature and Other Information for
Horizontal Positioning of TRV
Installation Process
The adapter must be securely screwed onto the valve by hand.
Avoid using tools to tighten the adapter, as this could damage the
components or aect compatibility.
Remove the battery cover and insert the batteries in the TRV as
shown in the image bellow.
Mount the TRV head on the radiator valve with the selected
adapter.
Optional: The TRV features a locking pin secured with the supplied hex
screw, which can be tightened using an Allen key to prevent unwanted
dismounting from the adaptor and ensure added security.
Optional
Mount the correct adaptor on the radiator's valve.
M28 - Please check if your valve requires the metallic washer for proper
installation and follow below instructions.
M30 - Follow the instructions bellow.
Danfoss Valve - Follow the instructions bellow.
1
2
M28
(with / without metallic washer)
M30 Danfoss RA
Upon initial power-up, the display will indicate
the symbol . This symbol will remain visible
until the actuator stem is fully retracted.
No input needed while this symbol is active.
3
Adjust the display orientation by using dial ring to accommodate
the TRV's installation in any position, whether horizontal or vertical.
4
Conrm by pressing Setup button.
washer
2
Calibration mode - After adjusting the display orientation, the
TRV will enter calibration mode, and the screen will display: .
Once the calibration is complete, the screen will display the
setpoint temperature.
To adjust temperature, short press the button then turn dial to desired
temperature.
5
TRV Pairing with Gateway in Oine Mode
1
1
3 4
5 s
UGE600
UG800
OR
5 s
5 s
UGE600
UG800
OR
5 s
TRV Pairing with Thermostat and/or
Receiver in Oine Mode
1
1
2
3.b
3.a
Select device
Make sure that all devices that is desired to be paired are in pairing mode
at the same time to ensure the connection process..
*For more details and information, please check the online full manual.
For optimal functionality, the Heating System selection must align
with your home's specic heating setup.
Operation Modes
AUTO
MODE
MANUAL
MODE
OFF MODE
(FROST PROTECTION)
2.a 2.b 2.c
TRV Pairing with Devices in Online Mode
Heating System Selection
In-App Advanced Options
TRV Pairing with Gateway in Online Mode
Factory Reset
3
Thermostat has been paired.
(RF symbol goes steady)
3
1
3
5
2
5
7
9
11
3
4
2
1
3
4
3
Ensure the valve is installed prior
to calibration. Failure to do so
will result in the display showing
the error code.
3
SP x2
SP
* SP = Short Press
* SP = Short Press
Flashing
SCAN FOR
APP INSTALLATION
1 2
SP + 3 seconds Press
SP
3
When is ashing, short press again
to make the RF symbol ash.
The unit is now in pairing mode.
SP
SP
Rotate the dial ring and
select for Thermostat
To pair with SALUS Thermostat.
SP
To pair with RX30RF.
Rotate the dial ring and select
for Boiler Receiver.
SP
6
8
4
10
Option Description
Open window
detected
Enable / Disable
If TRV detects that the room window is open = “OP” will appear on the
display. The valve will stay closed for 30 minutes, unless the tempera-
ture increases by at least 0.25°C or more.
Mode
Auto: follows the preset schedule
Manual ON: TRV is fully open (bypasses the thermostat).
Manual OFF: TRV is fully closed (bypasses the thermostat).
Low battery
valve position
Normally Open – Keeps the valve open when the battery is low.
Normally Closed – Shuts the valve o to save energy when the battery is low.
Heating control
Boiler System – Controls a private heating system
District Heating – Adjusts for centralized heating networks.
Temperature
calibration
Adjusts the displayed temperature to match the actual room temperature.
Valve minimum
opening point
Default: 8 (range: 5-35)
Set the lowest valve opening level. Useful if auto calibration doesn’t allow
enough heat through.
Caution! Too high value can cause constant ow when TRV is closed.
SP + 3 seconds Press
SP + 3 seconds Press
SP + 3 seconds Press
up to
(degrees in Celsius)
When is ashing, short press again
to make the RF symbol ash.
The unit is now in pairing mode.
** SP = Short Press
