© Copyright 2004 Smart-AVI, All Rights Reserved
Notice
The information contained in this document is
subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and fitness for any particular
purpose.
Smart-AVI will not be liable for errors contained herein
or for incidental or consequential damages in
connection with the furnishing, performance or use
of this material.
No part of this document may be photocopied,
reproduced or translated into another language with
out prior written consent from Smart-AVI.
For the complete manual, visit www.smartavi.com.
The FDX-2000 extends any single-link
DVI-D signal, PS2 keyboard, mouse, and
audio up to 1400 feet using
multimode fiber optics.
www.smartavi.com
User Manual
2840 N. Naomi Ave.
Burbank, California 91504
Phone: (818) 565-0011
Facsimile: (818) 565-0020
Technical Specifications
m_fdx2000-101909
FDX-2000
SPECIFICATIONS FDX-2000
Systems:
Windows 2000, XP and 2003 and Linux
Video Interface
DVI-D female
Single link
Resolution 1920 x 1200 @ 60 Hz
DDC internal table can be reprogrammed
Keyboard/mouse
Keyboard Mini din color coded, supports
PS2 compatible.
Mouse Mini din color coded, PS/2, wheel
mouse, 5-button mouse
Audio
Signal Type Stereo Audio
Bandwidth 15MHz, 0dB
Impedance 100 Ohm
Connector 3.5mm mini jack, Female
RS232
RS232 Data up to 57,600
DB9
Support TXD, RXD, GND
Dimensions(Inches)
Power Supply110/240 -5VDC-3A
Fiber
tGU!.VMUJNPEF
tGU!.VMUJNPEF
Fibre-Plug type SC
Compatible with all operating systems
Compatible with all major KVM Switches
Rack Mount options (19”): available
ORDER INFO
Model Description
FDX-2000 Point to point DVI-D,
keyboard, mouse,
Audio and RS232
ber extender.
Includes:
[FDX-TX2000,
FDX-RX2000,
2 x (PS5V3A)]
