Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 10/14/2011

For the most up-to-date information, please visit: www.startech.com

ADJDINKIT

Rackmount DIN Rail Kit with Top Hat/Mini/G Rails

*actual product may vary from photos

Packaging Contents

• 1xRackMountDINrailframe

• 1xAdjustableDINrailmountwithTopHatDINrail

• 1xMiniTopHatDINrail

• 1xG-typeDINrail

• 2xCarriageBolt

• 2xNut

• 4xPlasticWasher

• 2xM5Screw

• 2xM5Nut

• 1xInstallationGuide

System Requirements

• EIA-310Dcompliantrack/cabinet

• TopHat,Mini,orG-typeDINmountableequipment

Installation

1. DeterminethenecessarydepthfortheDINrailsandslidetheadjustableDINrailmountintotherackmountframefromthefront.

2. InsertthetwoboltswithwashersintothesidesoftheframeandthroughtheopeningsintheadjustableDINmount.

3. Usethenutswithwasherstofastentheboltsfromtheinsideoftheframe.

4. TheadjustableDINrailmountcomespreinstalledwiththeTopHatDINrail.ToswitchtooneoftheotherDINrailstyles,removethetwo

screwsthatholdtheDINrailtotheadjustablemount,replacetherail,andreattachthescrews.

5. MountthecompletedDINrailkitintotherack/cabinetandsecuretothemountingpostsusingtheappropriatemountinghardware.

NOTE: M5screwsandnutsareprovidedforcompatibleracks/cabinets.Alternativemountinghardwareshouldbeobtainedfromtherack/

cabinetmanufacturer.

6. MounttheDINrailcompatibledevices.

Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols

This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to

StarTech.com.WheretheyoccurthesereferencesareforillustrativepurposesonlyanddonotrepresentanendorsementofaproductorservicebyStarTech.com,oranendorsementoftheproduct(s)

towhichthismanualappliesbythethird-partycompanyinquestion.Regardlessofanydirectacknowledgementelsewhereinthebodyofthisdocument,StarTech.comherebyacknowledgesthatall

trademarks,registeredtrademarks,servicemarks,andotherprotectednamesand/orsymbolscontainedinthismanualandrelateddocumentsarethepropertyoftheirrespectiveholders.

Technical Support

StarTech.com’slifetimetechnicalsupportisanintegralpartofourcommitmenttoprovideindustry-leadingsolutions.Ifyoueverneedhelpwithyourproduct,visitwww.startech.com/supportandaccess

ourcomprehensiveselectionofonlinetools,documentation,anddownloads.

Forthelatestdrivers/software,pleasevisitwww.startech.com/downloads

Warranty Information

Thisproductisbackedbyalifetimewarranty.

Inaddition,StarTech.comwarrantsitsproductsagainstdefectsinmaterialsandworkmanshipfortheperiodsnoted,followingtheinitialdateofpurchase.Duringthisperiod,theproductsmaybereturned

forrepair,orreplacementwithequivalentproductsatourdiscretion.Thewarrantycoverspartsandlaborcostsonly.StarTech.comdoesnotwarrantitsproductsfromdefectsordamagesarisingfrom

misuse,abuse,alteration,ornormalwearandtear.

Limitation of Liability

InnoeventshalltheliabilityofStarTech.comLtd.andStarTech.comUSALLP(ortheirocers,directors,employeesoragents)foranydamages(whetherdirectorindirect,special,punitive,incidental,

consequential,orotherwise),lossofprots,lossofbusiness,oranypecuniaryloss,arisingoutoforrelatedtotheuseoftheproductexceedtheactualpricepaidfortheproduct.Somestatesdonotallow

theexclusionorlimitationofincidentalorconsequentialdamages.Ifsuchlawsapply,thelimitationsorexclusionscontainedinthisstatementmaynotapplytoyou.

Specications

Material SPCC

(1.6mmframe/1.0mmrails)

Colour Black

Mounting Height 2U

External Dimensions

(WxHxD) 482.6mmx88.9mmx358.4mm

Net Weight 1720g

Standards EIA-310D

Certications RoHS
