Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: October 30, 2019
Product Diagram (FTRST2)
PartFunction
1Footrest Platform• Rest feet on the Footrest Platform
2
Cable Management
Storage Space
• Store a Single Strip UL-Certied Power Bar
• Feed Cables out of cutouts in the back and sides
3Base
• Curved design to allow for a back and forth
movement
Warnings
• Always use dry footwear.
• Always store wet footwear and open containers of liquid away from the Rocking
Under-Desk Footrest.
• Do not stand on the Rocking Under-Desk Footrest.
Requirements
For the latest requirements please visit: www.startech.com/FTRST2.
• (Optional) Single Strip UL-Certied Power Bar x 1
Rocking Under-Desk Footrest - Cable Management
(Optional) Installation
1. Ensure the Single Strip UL-Certied Power Bar is powered O.
2. Access the Cable Management Storage Space by unfolding the Footrest Platform
from the Base.
3. Apply the 20 x 40 mm Tape to one side of the Single Strip UL-Certied Power Bar.
4. Press the taped side of the Single Strip UL-Certied Power Bar into the Cable
Management Storage Space with the Outlets pointed towards the front and the
Cable from the Single Strip UL-Certied Power Bar routed out of the side.
5. Route the Cables through the gap at the front and into the Single Strip UL-
Certied Power Bar and plug the Cables into the Outlets. (Figure 1)
6. Power On the Single Strip UL-Certied Power Bar.
7. Fold the Footrest Platform over the Base.
Note: Exercise caution when folding to avoid damaging the Cables.
8. Place the Rocking Under-Desk Footrest under the Desk.
Figure 1
1
2
3
Produktspecifikationer
| Varumärke: | StarTech.com |
| Kategori: | Inte kategoriserad |
| Modell: | FTRST2 |
| Vikt: | 1500 g |
| Bredd: | 350 mm |
| Djup: | 430 mm |
| Höjd: | 115 mm |
| Förpackningens bredd: | 370 mm |
| Snabbstartsguide: | Ja |
| Certifiering: | CE, TAA, RoHS, REACH |
| Lutningsvinkel: | -30 - 0 ° |
| Produktens färg: | Svart |
| Låddjup: | 455 mm |
| Vikt inkl. förpackning: | 1950 g |
| Ytterförpackningens höjd: | 480 mm |
| Produkter per ytterförpackning: | 5 styck |
| Ytterförpackningens längd: | 590 mm |
| Ytterförpackningens bredd: | 380 mm |
| Höjd (max.): | 100 mm |
| Halksäkert underlag: | Ja |
| Höjdjustering: | Nej |
