Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: January 6, 2021 9:41 AM

Product Diagram (RKCASTER2)

ComponentFunction

1Casters x 4

• Roll a Rack or Enclosure from location to

location.

• Maximum Weight Capacity stationary = 250 kg

rolling = 75 kg.

2Mounting Holes x 4

• Securely mount the Casters to a Rack or

Enclosure.

Package Contents

• Casters x 4

• M6 Screws x 16 + (*2)

• Washers x 16 + (*2)

• M6 Nuts x 16 + (*2)

(* Spare Parts)

Requirements

For the latest requirements, please visit www.startech.com/RKCASTER2

• 10 mm Wrench x 2

• Rack or Enclosure w/ Caster Holes

Set of Four 45x75 mm M6 Casters

Installing the Casters

Racks or Enclosures with Caster Mounting Holes

Note: The Rack or Enclosure must feature four sets of four Caster Mounting

Holes.

1. Ensure the Rack or Enclosure is positioned on it side.

Note: Two people are required for repositioning the Rack or Enclosure.

2. Align the Mounting Holes on the Casters with the Caster Mounting Holes on

the bottom of the Rack or Enclosure.

3. Insert the M6 Screws (x 4) through the Flat Washers (x 4).

4. Insert the four M6 Screw and Flat Washer Combinations through the Caster

Mounting Holes, the Rack or Enclosure and into the M6 Nut.

Installing the Casters

5. While securing the M6 Nut in place with a 10 mm Wrench, use a second 10 mm

Wrench to tighten the M6 Screw.

6. Repeat step 5 to secure the other three M6 Screws.

Note: If the Rack or Enclosure has Leveling Feet, adjust the Leveling Feet

after the Casters have been installed. Ensure the Rack or Enclosure is level. Please

refer to the Rack or Enclosure’s user manual for instructions on how to adjust the

Leveling Feet.

7. Repeat steps 2-6 to install the three remaining Casters.

1

2
