Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Diagram (ST4300USB3)
PortFunction
1Power LED• is receiving power.Solid:Hub
2USB-A Ports (4)• Used to connect USB devices to the .Hub
PortFunction
3Power Port
• Used with the , to power the Power Adapter
Hub.
4USB-B Port (Host)
• Used to connect the to the Host Computer
Hub.
Requirements
For the latest requirements, please visit , www.startech.com/ST4300USB3www.startech.
com/ST4300USB3EU, www.startech.com/ST4300USB3GBor
4 Port Black SuperSpeed USB 3.0 Hub
1
Installation
1. Connect the included power adapter to the USB hub. The power LED should light up
solid. Supplying external power is optional, however to ensure each USB port is fully
powered, connecting external power is recommended.
2. Connect the USB cable from the USB hub (type B port) to the host computer system.
NOTE: If connected to a USB 2.0 host port, the hub will only operate at USB 2.0 speeds.
3. The operating system should detect the hub immediately and automatically install it.
4. Once installation is complete, USB 1.x/2.0/3.0 devices should be able to be connected
to the hub and recognized.
Specications
Bus InterfaceUSB 3.0
Number of Ports4
Connectors
• USB-A x 4
• USB-B x 1
• DC Power x 1
LEDsPower x 1
Maximum Data Transfer RateUSB 3.0L 5 Gbps
Enclosure MaterialPlastic
Power Adapter5VDC, 2000mA, type M plug
Warning: Using an improper
power adapter may cause
damage to the HUB and any
connected devices. Ensure that
the correct adapter with a 5V
output is used.”
Operating Temperature0°C~55°C (32°F~131°F)
Storage Temperature-20°C~85°C (-4°F~185°F)
Humidity5%~95% RH
Dimensions152.0mm x 59.6mm x 23.5mm
Weight480g
2
