Instruction Manual

DE: Bedienungsanleitung - de.startech.com

FR: Guide de l'utilisateur - fr.startech.com

ES: Guía del usuario - es.startech.com

IT: Guida per l'uso - it.startech.com

NL: Gebruiksaanwijzing - nl.startech.com

PT: Guia do usuário - pt.startech.com

Manual Revision: 07/20/2012

For the most up-to-date information, please visit: www.startech.com

Packaging Contents

• 1x 6 Port USB Hub

• 1x USB 3.0 Cable

• 1x Universal Power Adapter

• 3x Power Adapter Plug (NA/ EU/ UK)

• 1x Instruction Manual

System Requirements

• USB enabled computer system with available USB 3.0 or 2.0 port

NOTE:Host computer not required to use Charging Port

• Available AC electrical outlet for use of Charging Port

• Microsoft® Windows® XP(32/64-bit)/ Server 2003(32/64-bit)/

Vista(32/64-bit)/ Server 2008 R2/ 7(32/64-bit), Apple® Mac OS®X,

or Linux®

ST7320USBC

6 Port USB 3.0/2.0 Hub with Charging Port

*actual product may vary from photos

4x USB 2.0 Ports

USB 3.0 host

port

Dedicated

Charging

Port

Power LED

2x USB 3.0

Ports

Power Switch

DC Power

Connector

*Backside Image

Installation

Hardware Installation

1. Make sure the power switch along the side of the hub is set to the

“O” position.

2. Connect the included power adapter to the USB hub. NOTE:

Unless using the Charging Port, supplying external power is

optional. However to ensure each USB port is fully powered,

connecting external power is recommended. Use of the Charging

Port requires external power.

3. Connect the USB cable from the USB hub (type B port) to the host

computer system.

NOTE: If connected to a USB 2.0 host port, all ports on the hub will

only operate at USB 2.0 speeds.

4. Toggle the switch along the side of the hub to the “On” position.

5. The operating system will detect the hub immediately and

automatically install it.

6. Once installation is complete, USB 1.x/2.0/3.0 devices should

be able to be connected to the hub and recognized by the

operating system.

Driver Installation

No driver or software installation is required for the supported

operating systems.

Specications

Host InterfaceUSB 3.0

Number of Ports6 (2x USB 3.0/ 4x USB 2.0)

Chipset IDVIA VL810E

External Connectors

2x USB 3.0 type A Female

4x USB 2.0 type A Female

1x USB 3.0 type B Female

1x DC Power Female

LEDs1x Power

Maximum Data Transfer Rate

USB 3.0: 5 Gbps

USB 2.0: 480Mbps

Maximum Power Output

USB 2.0: 500mA

USB 3.0: 900mA

Charging Port: 2000mA

Enclosure MaterialPlastic

Power Adapter5VDC, 4000mA, center positive

Operating Temperature0°C~85°C (32°F~185°F)

Storage Temperature-10°C~95°C (14°F~203°F)

Humidity5%~90% RH

Dimensions (LxWxH)99.0mm x 60.0mm x 20.0mm

Weight75.4g

Compatible Operating

Systems

Microsoft® Windows® XP(32/64-

bit)/ Server 2003(32/64-bit)/

Vista(32/64-bit)/ Server 2008

R2/ 7(32/64-bit), Apple® Mac

OS®X, Linux®
