Sida 1/2
1. Plug and play, easy installation
2. High resolution up to 1080p@60Hz full HD
3. Support point to point ,many to point configuration
4. Support HDMI1.3, compatible with HDCP1.2
5. 20 meters long range transmission sight distance
6. Smart por table design, excellent performance
7. Support select transmitter via switch button freely
8. Transmitter powered by input sources through HDMI port(when the
· Package Contents
· Important Safety Notice
· Introduction
· Features
· Installation Requirement
· Panel Des cription
· Connection
HDMI Extender TX
sender x1pcs
DC5V/2A power
adapter x1pcs
This HDMI wireless extender includes transmitter unit and receiver unit,
allows to transmit and extend HDMI signal up to 20 meters long away
wirelessly, it has strong anti-interference ability by running at 5GHz
operation frequency, and supports one to one , many to one connection.
really a very good solution for meeting, conference, home It is
entertainment and multi-media education etc.
Note:
1) Transmission distance will be different due to the environment.
2) Wall, brick or glass will shorten the signal cover range or cause big
signal loss.
1. HDMI source device (DVD, PS3, Set top box, PC etc)
2. HDMI display device like SDTV, HDT V, and projector with HDMI port.
1. HDMI Extender TX sender
2.HDMI Extender RX receiver
Please read below safety instructions carefully before installation and
operation:
1. Please pay attention to all the warnings and hints on this device.
2. Do not expose this unit to rain, moisture and liquid.
3. Do not put any stuff into the device.
4. Do not repaire the device or open the enclosure without professional
person guidence to avoid electronic shock.
5. Make sure good ventilation openings to avoid product overheating
damage.
6. Use DC5V/2A only. Make sure the specification matched if using 3rd
party DC adapters.
Wireless connections
indicator
Connect with HDMI source device
HDMI input
Power input
Switch button
Power indicator
Connect with HDMI display deviceHDMI output
Connect with DC5V/2A power adapter
Led keeps on when power on, blinks when it is
successfully connected
Power input
Connect the antenna
Antenna
Wireless connections
indicator
Data transmission
led
It keeps on when it is transmitting data, other wise,
it’
User manual
x1pcs
Connect with Micro USB power cable (optional)
To select transmitter input (many to one
connection use only)
1. Point to Point connection:
Connection instruction :
1) Plug the transmitter into the source device.
2) Connect HDMI output to HDMI display device by HDMI cable.
3) Power on the device (power led lights) and it works.
Note:
1) When the wireless signal transmits through wall, glass or othe r
LED indicator turn on when power on
Notebook
HDMI Extender RX
receiver x1pcs
2
3
1 4 5
HDMI INPUT
1
DC 5V
3 42 5 5
【 】NOTE This device can be powered from the HDMI source device (which
with HDMI input port) directly. However, when the transmission/connection
is not stable, or the output is not fluent, please connect Micro USB cable to
the DC5V port for power supply.
Micro USB Cable
x1pcs
HDMI dispiay
Power
10 pcs
2 many to one connection.
Led keeps on when there is HDMI input,
blinks slowly when it is successfully connected,
blinks fast when it is transmitting data
2
s off
HDMI Extender
TX sender HDMI Extender
RX receiver
Notebook
HDMI Extender
TX sender
HDMI Extender
TX sender
HDMI Extender
RX receiver HDMI dispiay
Notebook
HDMI output
HDMI output
transmission/connection is not stable, or the output is not fluent,
please connect Micro USB cable to the DC 5V por t for power supply)
9. Strong anti-interference ability by running at 5GHz operation
frequency
+
+
3
4
