OPERATING INSTRUCTIONS
MIXER AMPLIFIER
Thank you for purchasing TOA’s Mixer amplier.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
A-3606D, A-3612D, A-3624D, A-3648D
The gure represents the A-3648D.
About Firmware Upgrade
The latest rmware is available on the TOA DATA Library (https://www.toa-products.com/international/).
Perform a search for the product number "A-3606D, A-3612D, A-3624D, or A-3648D" and download
the latest rmware.
2
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS
............................................................................. 3
2. GENERAL DESCRIPTION .......................................................................... 5
3. FEATURES ............................................................................................................ 5
4. HANDLING PRECAUTIONS ...................................................................... 5
5. INSTALLATION PRECAUTIONS ............................................................. 6
6. THE DUCKER FUNCTION AND
THE PRIORITY BROADCAST FUNCTION ..................................... 6
7. NOMENCLATURE AND FUNCTIONS ................................................. 7
Front ............................................................................................................................. 7
Rear ............................................................................................................................. 8
8. CONNECTIONS ............................................................................................... 12
8.1. Speaker Connection ........................................................................................... 12
8.2. Input Terminal Connections and Settings ......................................................... 13
8.3. Connecting to the Remote Master Volume Control Terminal ............................. 15
8.4. Connecting to the Power Remote Control Output Terminal ............................... 15
8.5. Connecting to the Emergency Control Output Terminal ................................... 16
8.6. Connecting to the Zone Control IN/OUT Terminal ............................................. 16
8.7. Connecting to the Control Input Terminal ........................................................... 17
8.8. Connecting the External Equipment between the Line Output and
the Power Amplifier ............................................................................................ 17
8.9. Removable Terminal Plug Connection ............................................................... 18
9. SETTINGS ........................................................................................................... 19
9.1. Chime Tone Setting ............................................................................................ 19
9.2. Line Output Interlock Switch Setting .................................................................. 19
10. DUCKER DEPTH ADJUSTMENT ...................................................... 19
11. VOLUME ADJUSTMENT ......................................................................... 20
12. SPEAKER ZONE SELECTION ............................................................ 20
13. INSTALLING TO AN EQUIPMENT RACK .................................... 21
14. CONTROL SETTINGS ............................................................................. 21
15. PRIORITY BROADCAST FUNCTION .............................................. 22
15.1. Priority Broadcast ............................................................................................ 22
15.2. Priority Broadcast Mode ................................................................................... 22
15.3. Emergency Broadcast ...................................................................................... 24
15.4. Normal Broadcast ............................................................................................. 24
15.5. Relationship between Priority Broadcast
by Control Input/Emergency Broadcast and Power On/Off ............................. 24
15.6. Factory Default Settings ................................................................................... 25
15.7. Setting Examples and Operation Images ......................................................... 26
16. SETTINGS ON THE BROWSER ......................................................... 29
17. BLOCK DIAGRAM ....................................................................................... 30
18. SPECIFICATIONS ........................................................................................ 31
Accessories .............................................................................................................. 32
Optional products ...................................................................................................... 32
