Sida 1/8
INSTALLATION MANUAL
SPEAKER cONNEcTION bRAcKETS
HY-cN7b, HY-cN7W, HY-cN7b-WP, HY-cN7W-WP
Thank you for purchasing TOA's Speaker Connection Brackets.
Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.
TAbLE OF cONTENTS
1. SAFETY PREcAUTIONS ............................. 1
2. GENERAL DEScRIPTION ........................... 1
3. cOMPLETE ASSEMbLY
(Joined speaker example using
two HX-7 Series Speaker Systems) ........... 2
4.
JOINING TWO SPEAKER SYSTEMS
............ 2
5. INSTALLING JOINED SPEAKER SYSTEMS
(Indoor installations only) .......................... 6
6. SPEcIFIcATIONS ........................................ 8
1. SAFETY PREcAUTIONS
• Beforeinstallationoruse,besuretocarefullyreadalltheinstructions in thissection forcorrectandsafe
operation.
• Besuretofollowalltheprecautionaryinstructionsinthissection,whichcontainimportantwarningsand/or
cautionsregardingsafety.
• Afterreading,keepthismanualhandyforfuturereference.
• (HY-CN7BandHY-CN7Wonly)
Sincethebracketisdesignedforindooruse,donot
install it outdoors. If installed outdoors, the aging
of parts causes the speaker to fall off, resulting in
personal injury. Also, when it gets wet with rain,
thereisadangerofelectricshock.
• Donotuseothermethodsthanspeciedtomount
thebracket.Extremeforceisappliedtothespeaker
and it could fall off, possibly resulting in personal
injuries.
• Tighten each nut and bolt securely. Ensure that
the bracket has no loose joints after installation
to prevent accidents that could result in personal
injury.
• Thebracketisexclusivelyusedtojointogethertwo
HX-7 Series Speaker Systems. Using the bracket
in combination with other speakers may cause the
speaker to fall off, resulting in personal injury.
• Avoid installing the speaker in indoor swimming
facilities that are not well ventilated. In such
locations,themountinghardwaremaybevulnerable
to corrosion, eventually allowing the speaker to fall
resulting in personal injury.
• Avoid touching the bracket's sharp metal edge to
prevent injury.
• Havethebracketcheckedperiodicallybytheshop
fromwhereitwaspurchased.Failuretodosomay
result in corrosion or damage to the bracket that
could cause the speaker to fall, possibly causing
personal injury.
Indicatesapotentiallyhazardoussituationwhich,
if mishandled, could result in death or serious
personal injury.
WARNING
Indicatesapotentiallyhazardoussituationwhich,
ifmishandled,couldresultinmoderateorminor
personalinjury,and/orpropertydamage.
cAUTION
2. GENERAL DEScRIPTION
TheHY-CN7SeriesbracketsareusedtojointogethertwoHX-7Seriesspeakersystemsintoasinglesystem.
Joiningspeakerstogethernotonlyallowsmoreaccuratecontrolofdirectivityforlowerfrequencies,butalso
enhances the audibility of amplied speech in locations that suffer from long reverberation times or high
backgroundnoiselevels.TheHY-CN7BandHY-CN7Wbracketsaredesignedforindoorinstallations,andthe
HY-CN7B-WPandHY-CN7W-WPbracketsareforoutdoorinstallationsundereavesorotherareasprotected
fromdirectexposuretotheelements.
2
HY-CN7B, HY-CN7W, HY-CN7B-WP and HY-CN7W-WP Speaker Connection Brackets
HX-7 Series speaker
Side angle plate of Speaker
Connection Bracket
Rear angle bar of Speaker
Connection Bracket
Use the brackets to join.
First speaker
Second speaker
Protection cover Speaker molule A Speaker molule B
3. cOMPLETE ASSEMbLY
(Joined speaker example using two HX-7 Series Speaker Systems)
4. JOINING TWO SPEAKER SYSTEMS
Be sure to observe the following precautionary instructions.
Doingotherwisecouldresultinspeakersfallingandpotentiallycausing
personal injury.
• Donotjoin5ormoreHX-7SeriesSpeakerSystemstogetherina
single cluster.
• ThreeorfourHX-7SeriesSpeakerSystemsmaybejoinedtogether
only when the specified conditions for mounting brackets and
mountingmethodsaremet.
WARNING
Beforejoiningspeakersystems,layoutaprotectivesheet,corrugatedcardboardorothersoftmaterialonaat
surface,andperformallworkonthe2speakerswiththeirfrontbafesfacingdownward.Itisrecommendedthat
atleasttwopersonsbeinvolvedinjoiningspeakersystems.
Twospeakersystemscanbejoinedtogetherbyconnectingspeakermodules(AandBinthegurebelow)
usingthespeciedbrackethardware.
Note: Position speaker modules A and Bfacing in the same direction. In the gure, their side angle plate
protectioncoversarevisibleontheleftsideofeachspeakersystem.
