PENDANT SPEAKER PE-154BS

Thank you for purchasing TOA's Pendant Speaker.

Please carefully follow the instructions in this manual to ensure long, trouble-free use

of your equipment.

Traceability Information for Europe

Manufacturer:

TOA Corporation

7-2-1, Minatojima-Nakamachi, Chuo-ku, Kobe, Hyogo,

Japan

Authorized representative:

TOA Electronics Europe GmbH

Suederstrasse 282, 20537 Hamburg,

Germany

INSTRUCTION MANUAL

1. SAFETY PRECAUTIONS ........................... 1

2. GENERAL DESCRIPTION

AND FEATURES ......................................... 2

3. IMPEDANCE CHANGE .............................. 2

4. INSTALLATION .......................................... 3

5. DIMENSIONAL DIAGRAM ......................... 4

6. WIRING DIAGRAM...................................... 4

7. FREQUENCY RESPONSE (1 W, 4 m) ....... 5

8. SPECIFICATIONS ...................................... 5

TABLE OF CONTENTS

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read all the instructions in this section for correct and safe

operation.

• Be sure to follow all the precautionary instructions in this section, which contain important warnings and/or

cautions regarding safety.

• After reading, keep this manual handy for future reference.

When Installing the Unit

• Refer all installation work to the dealer from whom

the speaker was purchased. Installation work

requires extensive technical knowledge and

experience. The speaker may fall off if incorrectly

installed, resulting in possible personal injury.

• Install the speaker only in a location that can

structurally support the full weight of the unit and

mounting bracket. Doing otherwise may result in

the speaker falling down and causing personal

injury and/or property damage.

• Since the unit is designed for in-door use, do not

install it outdoors. If installed outdoors, the aging of

parts causes the unit to fall off, resulting in personal

injury. Also, when it gets wet with rain, there is a

danger of electric shock.

• Do not use other methods than specified to install

the speaker. Extreme force is applied to the

speaker and the speaker could fall off, possibly

resulting in personal injuries.

• Use screws that are appropriate for the ceiling's

material and structure. Failure to do so may cause

the speaker to fall, resulting in material damage

and possible personal injury.

• Ensure that all screws are securely tightened. If

they are loose after installation, the speaker could

fall down, possibly resulting in personal injury.

Indicates a potentially hazardous situation which,

if mishandled, could result in death or serious

personal injury.

WARNING

Produktspecifikationer

Varumärke:	Toa
Kategori:	högtalare
Modell:	PE-154BS
Vikt:	2330 g
Bredd:	186 mm
Djup:	186 mm
Höjd:	251 mm
Sladdlängd:	3 m
Ljudutgångskanaler:	- kanaler
Högtalarplacering:	Ceiling-monterbar
Antal förare:	2
Bashögtalare:	Ja
Känslighet:	91 dB
Produktens färg:	Vit
Uteffekt (RMS):	- W
diskanthögtalare:	Ja
Material, hölje:	Polystyren
Frekvensområde:	70 - 20000 hz
Anslutningsteknologi:	Kabel
Woofer diameter (imperial):	5 "
Bluetooth:	Nej
Antal woofer-drivenheter:	1
Disktanthögtalare diameter:	1 "
Antal tweeter förare:	1
