Sida 1/4

1. SAFETY PRECAUTIONS

• Before installation or use, be sure to carefully read

all the instructions in this section for correct and

safe operation.

• Be sure to follow all the precautionary instructions

in this section, which contain important warnings

and/or cautions regarding safety.

• After reading, keep this manual handy for future

reference.

Indicates a potentially hazardous situation which,

if mishandled, could result in death or serious

personal injury.

WARNING

• Refer all installation work to the dealer from whom

the speaker was purchased. Installation onto the

ceiling requires extensive technical knowledge and

experience. The speaker may fall off if incorrectly

installed, resulting in possible personal injury.

• Install the unit only in a location that can structurally

support the weight of the speaker and the mounting

bracket. Doing otherwise may result in the speaker

falling down and causing personal injury and/or

property damage.

• Owing to the speaker's size and weight, be sure

that at least two persons are available to install the

speaker. Failure to do so could result in personal

injury.

• Donotuseothermethodsthanspeciedtomount

the bracket. Extreme force is applied to the bracket

and the speaker could fall off, possibly resulting in

personal injuries.

• Use safety wires when installing speakers. If not

used, personal injury could result if a speaker

should accidentally fall.

• Attach the safety wire to the speaker. If not attached,

the speaker could fall off, resulting in personal injury.

• Use nuts and bolts that are appropriate for the

ceiling’sstructureandcomposition.Failuretodoso

may cause the speaker to fall, resulting in material

damage and possible personal injury.

• Tighten each nut and bolt securely. Ensure that

the bracket has no loose joints after installation

to prevent accidents that could result in personal

injury.

• Use the HX-7B-WP or HX-7W-WP Speaker System

in combination. Doing otherwise may cause the

speaker to fall off, resulting in personal injury.

• Do not mount the speaker in locations exposed

to constant vibration. The rigging bracket can be

damaged by excessive vibration, potentially causing

the speaker to fall, which could result in personal

injury.

• Avoid installing the speaker in locations close to the

seashore or in indoor swimming facilities that are

not well ventilated. In such locations, the bracket

may be vulnerable to corrosion, eventually allowing

the speaker to fall resulting in personal injury.

Indicates a potentially hazardous situation which,

if mishandled, could result in moderate or minor

personal injury, and/or property damage.

CAUTION

• Avoid touching the bracket's sharp metal edge to

prevent injury.

• Do not stand or sit on, nor hang down from the

bracket as this may cause the speaker to fall down

or drop, resulting in personal injury and/or property

damage.

• Have the bracket checked periodically by the shop

from where it was purchased. Failure to do so may

result in corrosion or damage to the speaker or its

rigging bracket that could cause the speaker to fall,

possibly causing personal injury.

INSTALLATION MANUAL

SPEAKER RIGGING BRACKET HY-TM7B-WP

HY-TM7W-WP

ThankyouforpurchasingTOA’sSpeakerRiggingBracket.

Please carefully follow the instructions in this manual to ensure long, trouble-free use of your equipment.

Produktspecifikationer

Varumärke:	Toa
Kategori:	högtalare
Modell:	HY-TM7W-WP
Vikt:	2500 g
Bredd:	433 mm
Djup:	295 mm
Höjd:	57 mm
Material:	Rostfritt stål
Kompatibilitet:	HX-7W-WP
Produktens färg:	Metallisk
Antal per förpackning:	1 styck
Skruvar medföljer:	Ja
