Issue 3

1 947037

V-1039A

7 WATT EXPLOSION PROOF

PAGING HORN/AMPLIFIER ASSEMBLY

INTRODUCTION

These instructions provide identification,

installation and technical assistance information

for the V-1039A, Explosion Proof One-Way

Amplified Horn Assembly.

The V-1039A is a one-way explosion proof

paging horn for use with Valcom single or

multi-zone paging equipment.

The V-1039A is UL listed for use in the following

atmospheres:

Class I, Division I, Groups C & D: Gas

Atmospheres

This paging unit has received an FCC type KX

registration and is designed to be used with FCC

registered key telephone systems. In

accordance with FCC rules with applicable

tariffs, this Paging Unit may only be installed with

the authorization of the host system.

Installations may be made by Valcom, Inc., an

authorized agent of the same, equipment

manufacturers, telephone companies, registered

telephone refurbishers, and those qualified for

installation of FCC registered systems under

FCC Rules Section 68.215. The FCC

Registration Number, BAF9I7-69358-KX-N, will

be listed in the affidavits filed with the telephone

company; it will also be recorded in the system

log kept by installation and maintenance

personnel.

SPECIFICATIONS

The V-1039A consists of an explosion proof horn

speaker with a built-in one-way 7 watt amplifier.

Features

 7 watts

 Self-contained amplifier

 Includes V-1092 wall mount volume

control

 Weatherproof

 Wide dispersion angle

 Metal and polycarbonate construction

 Omni-directional mounting bracket

 1/2" conduit access

Dimensions/Weights

 V-1039A: 6.0"H x 14"W x 17.5"D

(15.2cmH x 35.56cmW x 44.45cmD)

19 lbs. (8.62kg)

 V-1092: 4.5"H x 2.75"W x 2.8"D

11.43cm H x 6.99cm W x 7.11cm D)

0.8 lbs. (.36kg)

Power Requirements

 1.0 amp max unfiltered –24 Vdc

("B" Battery)

Environment

 Temperature: -4 to 130 F (-20 to 55 C)

 Humidity: 0-95% non-precipitating

Produktspecifikationer

Varumärke:	Valcom
Kategori:	ej kategoriserat
Modell:	V-1039A
Vikt:	8550 g
Bredd:	355.6 mm
Djup:	444.5 mm
Höjd:	152.4 mm
Rekommenderad användning:	Andra
Ljudutgångskanaler:	1.0 kanaler
Högtalarplacering:	Ceiling-mountable, Wall-mountable
Känslighet:	115 dB
Förstärkare:	Inbyggd
Produktens färg:	Grå
Vikt inkl. förpackning:	9675 g
Uteffekt (RMS):	7 W
Antal produkter som medföljer:	1 styck
Material, hölje:	Epoxy, Metal
Frekvensområde:	250 - 12000 hz
Anslutningsteknologi:	Kabel
Ström:	1 A
Högtalartyp:	1-vägs
Likströmsdriftspänning:	24 V
