Issue 8

1 947925A

V-9925A

LOUD WARBLE RINGER WITH VOLUME CONTROL

5 WATT -24VDC

INTRODUCTION

These instructions contain the specifications and

guidelines necessary to install, operate and maintain

the V-9925A, 5-Watt Loud Warble Ringer with

Volume Control.

SPECIFICATIONS

The V-9925A Loud Warble Ringer is a

self-contained 5-Watt electronic ringer which can be

used for either interior or exterior signaling

applications. The unit is designed to allow a loud

warble to be broadcast as long as input signal is

present. The input signal should be interrupted or

controlled by the ringing interval.

Application

 Loud speaker tone signaling for key systems,

intercoms, PABXs

 Outside signaling for incoming calls into a key

system

 Signaling in a noisy environment

Features

 5 Watt amplifier

 Volume control

 High efficiency horn

 Tone generation circuitry

Coverage

Refer to the following table for speaker coverage.

The first number given is the side to side distance for

mounting the speakers. It is also the distance in front

of the speaker that you can expect to hear a good

quality signal. The second number is the area being

covered in square feet.

Location Distance Area

Quiet 220 ft. 48,400 sq. ft.

Moderate 160 ft. 25,600 sq. ft.

Noisy 80 ft. 6,400 sq. ft.

Very Noisy 40 ft. 1,600 sq. ft.

Environmental

 Temperature: -20 to +55°C

 Humidity: 0 to 95% (non-precipitating)

Dimensions/Weight

 6.50"H x 8.20"W x 10.40"D,

plus mounting base

(16.51cm H x 20.83cm W x 26.42cm D)

 3.6 lbs. (1.63kg)

Signal/Power Requirements

 Power Supply: -24VDC, 500mA ("B" Battery)

(10 Valcom power units)

 Signal Source: 105VAC or 20VAC

Produktspecifikationer

Varumärke:	Valcom
Kategori:	ej kategoriserat
Modell:	V-9925A
Bredd:	208.2 mm
Djup:	264 mm
Höjd:	165.1 mm
Rekommenderad användning:	Andra
Ljudutgångskanaler:	1.0 kanaler
Högtalarplacering:	Ceiling-monterbar
Antal förare:	1
Förstärkare:	Inbyggd
Produktens färg:	Beige
Uteffekt (RMS):	5 W
Equalizer:	Nej
Frekvensområde:	- hz
Anslutningsteknologi:	Kabel
Strömingång:	Ja
Ström:	0.5 A
AC-adapter, nätspänning:	24 V
Högtalartyp:	1-vägs
