TIME AND MANAGEMENT

GENERAL CHARACTERISTICS

TECHNICAL INFORMATION

CONNECTION DIAGRAMDIMENSIONS (mm)

Front viewSide viewDiagram

Digital time switches with trippers for the management of electrical loads over time available in both daily

and weekly version.

They combine the accuracy of a digital clock with the ease of a programming typical of the trippers clocks.

The cover on the back of the device allows the replacement of the battery once exhausted.

MICRODigital time switches

1 Backlit display for viewing of the programming, time

and relay status

2Container: 1 DIN module

3Text guide

4Cover for battery replacement

DIGITAL SWITCHES WITH VIRTUAL TRIPPERS

DAILY / WEEKLY

•Power supply: 230 V AC 50/60 Hz

•Daily or weekly version

•Automatic summer time update

•Product supplied with the date and time set in the factory

•Backup battery for maintaining the date and time also without power from the mains

•Battery life: 4 years (replaceable by accessing the cover)

•Low battery signal

•Manual override of the relay (temporary or permanent)

•Switching of the relay only in the presence of power supply

•Backlighting of the display always on when the device is mains powered

(auto power o for energy saving in the case of blackout)

CodeModelDescriptionn. relays

VE758100micro DTime switch with daily programming1

VE758200micro WTime switch with weekly programming1

•running program always visible

on the display

•48 virtual trippers

for a resolution of 30 minutes

Power supply230 (-15% ÷ +10%)V AC

Frequency Hz50 / 60

AbsorptionVA (W)5.5 (1)

Output1 relay normally open

Capacity at 250 V AC16 (10)A

Battery life4 years (Lithium battery CR-1632)

Charge reserve (for battery replacement)1 minute

Switchings in case of power failureNO

Programming resolution30 minutes

Programming:

- micro Ddaily (1 program)

- micro Wweekly (7 programs)

Operating accuracy± 1 second/day at 25°C

Operating temperature-20 ÷ +50°C

Storage temperature-10 ÷ +70°C

Operating humidity20 ÷ 90 %RH

non condensing

Container1 DIN module

Degree of protectionIP20

REFERENCE STANDARDS

Compliance with Community Directives:

2014/35/EU (LVD) • 2014/30/EU (EMCD)

is declared with reference

to the following standards:

EN 60730-2-7

CONNECTABLE LOADS

Incandescent 2000 W

Fluorescent (compensated) 250 VA

Low voltage halogen 1000 VA

Halogen (230 V~) 2000 W

Low consumption (CFL) 200 VA

Low consumption (Downlights)200 VA

Led 25 VA

12

3

4

MICRO-ENG-201903
