Sida 1/15
Rev. 0913 CART-550-SS, manual.doc
Copyright 2013 Vestil Manufacturing Co. Page 1 of 15
CART-550-SS & CART-1100-SS
Instruction Manual
After delivery, immediately remove the packaging from the product in a manner that preserves the packaging
and maintains the orientation of the product in the packaging; then inspect the product closely to determine whether it
sustained damage during transport. If damage is discovered during the inspection, immediately record a
complete description of the damage on the bill of lading. If the product is undamaged, discard the packaging.
NOTES:
1) Compliance with laws, regulations, codes, and non-voluntary standards enforced in the location where the
product is used is exclusively the responsibility of the owner/end-user.
2) Vestil is not liable for any injury or property damage that occurs as a consequence of failing to apply either:
a) the instructions in this manual; or b) information provided on labels affixed to the product. Neither is Vestil
responsible for any consequential damages sustained as a result of failing to exercise sound judgment while
assembling, installing, using or maintaining this product.
Vestil Manufacturing Co.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com e-mail: sales@vestil.com
Table of Contents Page
Hazard Identification: explanation of signal words……………………………………………………………………. 2
Safety Guidelines….……………………………………………………………………………………………………… 2
Product Introduction……………………………………………………………………………………………………… 3
Bills of materials for CART-550-SS and 1100-SS…………………………………………………………………….. 5, 7
Assembly Instructions……………………………………………………………………………………………………. 8
Use Instructions…………………………………………………………………………………………………………... 9-11
Loading…………………………………………………………………………………………………………………..... 9
Lift Table Operation……………………………………………………………………………………………………… 10
Hydraulic System Operation……………………………………………………………………………………………. 10-11
Inspections & Maintenance……………………………………………………………………………………………… 12
Troubleshooting…………………………………………………………………………………………………………... 13
Table of Figures
FIG. 1: CART-550-SS Exploded Parts Diagram……………………………………………………………………… 4
FIG. 2: CART-1100-SS Exploded Parts Diagram…………………………………………………………………….. 6
FIG. 3: Hydraulics Diagram……………………………………………………………………………………………… 8
FIG. 4: Spline and Pin Connection……………………………………………………………………………………… 8
FIG. 5: Handle Insertion…………………………………………………………………………………………………. 8
FIG. 6: Pedal Attachment……………………………………………………………………………………………….. 8
FIG. 7A & 7B: Proper Load Positioning (Top View & Side View)…………………………………………………… 9
FIG. 8: Caster Brake Lever……………………………………………………………………………………………… 10
FIG. 9: Hydraulic Control Pedal Positions……………………………………………………………………………... 11
FIG. 10: Maintenance Prop Installation………………………………………………………………………………… 12
FIG. 11: Label Placement……………………………………………………………………………………………….. 14
Page 2 of 15
HAZARD IDENTIFICATION: explanation of signal words
This manual uses SIGNAL WORDS to indicate the likelihood of personal injuries, as well as the probable
seriousness of those injuries, if the product is misused in the ways described. Other signal words call
attention to uses of the product likely cause property damage.
The signal words used appear below along with the meaning of each word:
Identifies a hazardous situation which, if not avoided, WILL result in
DEATH or SERIOUS INJURY. Use of this signal word is limited to
the most extreme situations.
Identifies a hazardous situation which, if not avoided, COULD result
in DEATH or SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result
in MINOR or MODERATE injury.
Identifies practices likely to result in product/property damage, such
as operation that might damage the product.
Each person who assembles, installs, uses, or maintains this product should read the entire manual and
fully understand the directions in advance. If after reading the manual you do not understand an instruction,
ask your supervisor or employer for clarification, because failure to adhere to the directions in this manual
might result in serious personal injury.
SAFETY GUIDELINES
Vestil diligently strives to identify foreseeable hazards associated with the use of its products. However,
material handling is inherently dangerous and no manual can address every conceivable risk. The end-user
ultimately is responsible for exercising sound judgment at all times.
Failure to read and understand the entire manual before assembling, installing, using
and servicing the product is a misuse of the product. If this product is used improperly or carelessly, the
user and/or bystanders might sustain serious personal injuries. To reduce the likelihood of injury:
DO NOT modify the product in any way UNLESS you first obtain written approval from Vestil.
Unauthorized modifications automatically void the Limited Warranty and might make the product unsafe to
use.
DO NOT attempt to service a loaded cart. Unload the cart and install maintenance props according to the
directions on p. 13 BEFORE working on the cart. DO NOT work under the lift without using the maintenance
devices.
DO NOT attempt to lift or transport loads that exceed the capacity of the cart.
DO NOT stand, sit or ride on the cart.
DO NOT put hands or feet under the deck at any time UNLESS the maintenance props are in place.
Stand clear of the cart while the lift table is moving.
Keep clear of pinch points! As the deck rises and lowers, pinch points occur between the leg weldments
(see Fig. 11, p. 15). NEVER reach into or put any part of your body inside the scissors mechanism.
DO NOT use the scissors lift cart UNLESS all safety labels are in place and readable.
DO NOT use the cart if you hear unusual sounds while raising or lowering the deck.
Always watch the load carefully while raising or lowering the deck.
ONLY use the cart on compacted, improved surfaces.
DO NOT leave a loaded cart unattended. ALWAYS unload the cart, and return it to the designated
storage location BEFORE you leave the cart unattended.
DO NOT store the cart outdoors or in corrosive environments.
Proper use, maintenance, and storage are essential for this product to function properly.
o Always use this product in accordance with the instructions in this manual and consistent with any training
relevant to machines, devices, etc. used in conjunction with this product.
o Periodically lubricate moving parts.
o Keep the product clean & dry.
o Only use approved replacement parts. To order replacement or spare parts for this equipment, contact
the factory.
