Sida 1/5
Rev. 8/2/2024 VGP-100, VGP-100-FF, MANUAL
Copyright 2024 Vestil Manufacturing Co. Page 1 of 5
VGP-100
VGP-100-FF
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description of
it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The Department
can also be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from https://www.vestil.com/page-
manuals.php.
Vestil Manufacturing Co.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
Web: www.vestil.com e-mail: info@vestil.com
Table of Contents
Page
Signal Words……………………………………………….……………………………………………….... 2
2
Safety Instructions.……………………………………………………..………………………….…………
2
Using the Pipe Carrier………………………………………………………………………………………..
2
Exploded View and Bill of Materials………..……………………………………………………………….
3
Record of Satisfactory Condition……………………………………………………………………………
4
Inspections & Maintenance……………………………………………………………………………….....
4
Labeling Diagram.…………...………………………………………..……………....................................
4
Limited Warranty…………………………………………….………………………………………………..
5
Rev. 8/2/2024 VGP-100, VGP-100-FF, MANUAL
Copyright 2024 Vestil Manufacturing Co. Page 2 of 5
SIGNAL WORDS
This manual uses SIGNAL WORDS to indicate the likelihood that a particular action will cause
personal injuries or
property damage. Signal words also specify the level of seriousness of injury if
the product is misused in the ways
described. The following signal words are used in this manual.
Identifies a hazardous situation which, if not avoided, WILL result in DEATH
or SERIOUS INJURY. Use of this signal word is limited to the most extreme
situations.
Identifies a hazardous situation which, if not avoided, COULD result in
DEATH or SERIOUS INJURY.
Indicates a hazardous situation which, if not avoided, COULD result in MINOR
or MODERATE injury.
Identifies practices likely to result in product/property damage, such as operation
that might damage the product.
SAFETY INSTRUCTIONS
Vestil strives to identify all foreseeable hazards associated with the use of its products. Material
handling is dangerous and no manual can address every conceivable risk. Ultimately, the most
effective way to prevent injury is to apply sound judgment whenever using this device.
Improper or careless use of this product could result in death or serious personal injuries.
Read and understand the entire manual before assembling, installing, using or servicing the product.
Read the manual to refresh your understanding of proper use and maintenance procedures.
DO NOT attempt to resolve any problem(s) with the product unless you are both qualified to do so
and confident that it will be safe to use afterwards.
DO NOT modify the product in any way UNLESS you first obtain written approval from Vestil.
Unapproved modifications automatically void the LIMITED WARRANTY on p. 5 and might make the
product unsafe to use.
DO NOT sit, or ride, on the carrier.
DO NOT transport loads up or down sloping terrain. The load should remain level during transport to
prevent it from sliding and/or becoming unbalanced.
DO NOT transport people with the carrier. The carrier must only be used to transport material. It is
specifically designed to transport pipe not exceeding 20ft. in length.
DO NOT exceed the capacity: VGP-100 = 600 pounds (272kg); VGP-100-FF = 1,000 pounds
(454kg). Capacity information is provided in on-product labeling. See Label 1153 in the LABELING
DIAGRAM on p. 4.
DO NOT pull the carrier. Always push the carrier so that it and all loads applied to it remain in view.
Do not overload the carrier. Only load as much pipe onto the carrier as you can comfortably manage.
Inspect the product according to the instructions in INSPECTIONS & MAINTENANCE on p. 4. DO
NOT use the product unless it is in SATISFACTORY CONDITION.
DO NOT use this device UNLESS all product labels are readable and undamaged. See LABELING
DIAGRAM.
DO NOT stop suddenly while transporting pipes with the carrier. Stopping suddenly could cause
pipes to slide forward and become unbalanced or fall off of the carrier.
Proper use, maintenance, and storage are essential for this product to function properly.
o Do not shock load, i.e. drop pipe onto the carrier. Carefully load pipe onto the carrier.
o Always use this product in accordance with the instructions in this manual and consistent with any
training relevant to machines, devices, etc. used in conjunction with this product.
o Keep the product clean & dry. Periodically lubricate moving parts.
USING THE PIPE CARRIER
Center the pipes lengthwise in the carrier to balance the load.
Make sure that the load is stable in the carrier before moving it. Transport pipes with the carrier over
even, level ground. Move only at controlled speeds. Avoid sharp turns and sudden stops while
transporting pipes with the carrier.
