Sida 1/11
Version 1.04 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 1
Ambient Weather WH31SM Soil Moisture Sensor
Table of Contents
1. Introduction ..................................................................................................................................... 1
2. Features ........................................................................................................................................... 2
3. Getting Started ................................................................................................................................ 3
4. Setup Guide ..................................................................................................................................... 3
4.1 Batteries .................................................................................................................................. 3
4.2 Pre-installation ....................................................................................................................... 3
4.3 Sensor Placement ................................................................................................................... 4
5. Console ........................................................................................................................................... 5
5.1 Display ................................................................................................................................... 5
5.2 Sensor Channel Designation .................................................................................................. 5
5.3 Calibration .............................................................................................................................. 6
5.3.1 0% Soil Moisture Set Point ................................................................................................ 6
5.3.2 100% Soil Moisture Set Point ............................................................................................ 6
6. AmbientWeather.net ........................................................................................................................ 7
7. Specifications .................................................................................................................................. 8
7.1 Sensor Specifications ............................................................................................................. 8
7.2 Wireless Specifications .......................................................................................................... 8
7.3 Power Consumption ............................................................................................................... 8
8. Troubleshooting .............................................................................................................................. 8
9. Liability Disclaimer ........................................................................................................................ 8
10. FCC Statement............................................................................................................................ 9
11. Warranty Information ................................................................................................................. 9
12. California Prop 65 .................................................................................................................... 10
1. Introduction
Thank you for your purchase of the Ambient Weather WH31SM Soil Moisture sensor. The following
user guide provides step by step instructions for installation, operation, and troubleshooting. To
download the latest manual and additional troubleshooting tips, please visit:
https://ambientweather.com/faqs/question/tags/tag/WH31SM/
The soil moisture sensor is not a stand-alone device and requires a WS-2000 or WS-5000 weather
station console to view and upload the data to our cloud hosting service at AmbientWeather.net.
To see if your weather station is compatible, please visit:
Version 1.04 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 2
https://ambientweather.com/faqs/question/tags/tag/WH31SM/
The following WS-2000 and WS-5000 console firmware versions or greater support the soil moisture
sensor:
Firmware revision number: V1.6.0
Wi-Fi Firmware: AMBWeatherV4.2.0
For details on updating the firmware, consult your weather station user manual.
No Item
1 LED Indicator (RF transmission)
2 Battery Cap
3 Soil Moisture Sensor cap
4 Green Waterproof End Cap
Figure 1
2. Features
The sensor features a ceramic cap, which acts like a breathing filter for exchanging soil moisture to
the internal sensor. This filter makes the sensor less sensitive to soil density (clay, sand, soil, potting
soil, etc.).
Other features include:
Measures soil moisture content every 71 seconds.
Ceramic coded for more accurate measurement.
Calibration for different soil types (WS-2000 and WS-5000 only).
Version 1.04 ©Copyright 2020, Ambient LLC. All Rights Reserved. Page 3
Long wireless range, up to 300 feet (100 meters) line of sight (100 feet under most
conditions).
Supports up to 8 channels.
3. Getting Started
The Ambient Weather WH31SM soil moisture sensor includes the following:
QTY Item
1 Soil Moisture Sensor: 6" length x 3.5 width x 1" diameter
1
User Manual
1
Green
Waterproof End Cap
4. Setup Guide
4.1 Batteries
The soil moisture requires 1 x AA batteries (not included). We recommend Energizer Lithium batteries
for longer life and a wider operating temperature range.
Remove the battery cap as shown in Figure 2A and insert 1 x AA battery. Close the battery
door.
Figure 2A
Figure 2B
After inserting the AA battery (positive side first), install the battery cap. Then, while turning
the green waterproof end cap clockwise, slide the waterproof cap over the battery
compartment securing the battery compartment from moisture as in figure 2B
Note: Remove the green waterproof end cap by twisting it clockwise to prevent battery cap from
becoming lodged in the waterproof cap.
4.2 Pre-installation
Before installing the sensor into its permanent location, we recommend verifying proper operation.
