Version 1 ©Copyright 2016, Ambient LLC. All Rights Reserved. Page 1 .0
Ambient Weather WS-2063 Indoor Temperature and
Humidity Monitor with Backlight User Manual
Table of Contents
1. Introduction ..................................................................................................................................... 1
2. Getting Started ................................................................................................................................ 2
2.1 Monitor Features .................................................................................................................... 2
2.2 Parts List ................................................................................................................................. 3
2.3 Powering Up ........................................................................................................................... 3
3. Monitor Display .............................................................................................................................. 3
3.1 Temperature Display .............................................................................................................. 3
3.2 Humidity Display ................................................................................................................... 3
4. Specications and Accuracy ........................................................................................................... 4
4.1 Measurement Specications ......................................................................................................... 4
4.2 Power Consumption ...................................................................................................................... 4
5. Troubleshooting Guide .................................................................................................................... 5
6. Liability Disclaimer ........................................................................................................................ 5
7. Warranty Information ...................................................................................................................... 6
1. Introduction
Thank you for your purchase of the Ambient Weather WS-2063 Indoor Temperature and Humidity
Monitor with Backlight. The following user guide provides step by step instructions for installation,
operation and troubleshooting. To download the latest full sized manual and additional
troubleshooting tips, please visit:
http://ambientweather.wikispaces.com/ws2063
Version 1 ©Copyright 2016, Ambient LLC. All Rights Reserved. Page 2 .0
2. Getting Started
2.1 Monitor Features
Figure 1
No
Description
No
Description
1
LIGHT Button. Press to turn on the back
light for 5 seconds.
7
OUT TEMP sensor (optional) jack.
2
IN/ OUT button.
- When the optional probe is connected,
press to switch between the indoor and
probe temperature.
- Press and hold for 2 seconds to scroll
between indoor and probe temperature
automatically every 5 seconds. Press
again to stop the scroll mode.
8
NIGHT ON/OFF slide switch.
Slide to the position to activate the ON
night light feature.
- When the switch is the backlight will ON,
turn on automatically when the room is
dim or dark.
- Slide to to turn the backlight feature OFF
off.
3
CHECK/RESET button.
- Press to instantly check the current
temperature, humidity and low battery.
- Press and hold for 2 seconds to reset the
minimum and maximum data.
9
button °C / °F
- Press it to switch between Celsius and
Fahrenheit.
4
LCD Display
10
button RESET
- Pres to restore to default values. s
- Press to begin 24 hour minimum and
maximum timer.
5
MANUAL/Past 24hr slide switch.
- Slide to to record the MANUAL
minimum and maximum between manual
resets.
- Slide to to record the Past 24hr
minimum and maximum every 24 hours
(based on power up or manual reset).
11
Battery compartment
6
OUT TEMP sensor (optional)
12
Suspension eye for mounting to a wall.
Version 1 ©Copyright 2016, Ambient LLC. All Rights Reserved. Page 3 .0
No
Description
No
Description
- Plug in the optional probe to measure
the probe temperature.
2.2 Parts List
QTY
Item
1
Monitor
Frame Dimensions 2.8(W) x 4.05(H) x 1.06(D) in :
1
User Manual
2.3 Powering Up
1. Remove the battery door on the top of the monitor and insert 2 new AA batteries, according to
the polarity information marked on the battery compartment, and replace the battery door.
2. Once the batteries are inserted, all of the LCD segments will light up briey.
3. The 24 hour timer will begin for resetting the minimum and maximum temperature and
humidity.
4. Allow a few minutes for temperature to stabilize, and approximately 20 minutes for the
humidity to stabilize.
3. Monitor Display
3.1 Temperature Display
When you plug in the optional temperature probe, the display will automatically switch to the probe
temperature.
When the temperature is below -40°F, the icon appears on display. LO
When the temperature is above 158°F, the icon appears on display. HI
Figure 2
3.2 Humidity Display
The house humidity icon identies high and low humidity conditions.
When the relative humidity is less than 30%, LOW is displayed.
When the relative humidity is between 30% and 50%, this is considered in the good range.
When the humidity is greater than 50%, is displayed. HIGH
