www.avsl.com 1 847 User Manual 28. UK

4K HDMI 2.0 Splitter

Item ref: 128.847 UK

User Manual

Slimline 4K HDMI splitter to easily connect a single HDMI source to up to 8 displays at the same time. This

updated version will support HDMI v2.0 which is compatible with the latest 4K digital TV boxes producing

3840 x 2160 @ 60Hz resolution.

• Supports HDMI v2.0 resolutions up to 3840 x 2160 @ 60Hz for compatibility with the latest 4K digital TV

boxes

• Simple connection and installation

• Sleek design with tough metal chassis

• Gold plated HDMI connectors for optimum signal transfer

• Supports DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD audio formats

• Ideal for entertainment, hospitality and other commercial venues requiring multiple display feeds from a

single HDMI source

Technical specifications:

HDMI version

2.0b

Video resolution

Up to 3840 x 2160 @ 60Hz

Display colours

8/10/12bit deep colour

Audio format

DTS-HD, Dolby True, DTS, Dolby-AC3 and DSD

HDCP version

2.2

Max. bandwidth

600 MHz

Max. baud rate

6Gbps

Max. working current

1600 mA

Transmission distance

35m max 4K @ 30Hz and FHD or 10m max 4K @ 60Hz

Power supply

Input: AC (50Hz, 60Hz) 100-240V, Output: DC5V/2A

Dimensions

276 x 136 x 24 mm

Weight

660g

Application diagram:

www.avsl.com 1 847 User Manual 28. UK

Connection instructions:

• Using an HDMI lead of the required length connect the output of the source device to the input of the

splitter : to maintain 4K resolution, always use 4K certified HDMI leads. . NOTE

• Using HDMI leads of the required length connect the outputs of the splitter to the inputs of the display

devices. : m maximum combined cable length for @30Hz or FHD signals and m maximum NOTE 35 4K 10

combined cable length for @60Hz signals. 4K

• Connect the 5V power adap r (supplied) to the splitter; plug into a mains outlet and switch on. to

• Blue LEDs on the back of the splitter will illuminate when the source and display devices are connected

and powered on.

In the b : ox

1. HDMI Splitter 1x8

2. 5V DC Power Adaptor

3. User Manual

Warning:

• For reasons of electrical safety, this device must never be immersed in water, e osed to damp conditions xp

or excessive force.

• Do not use this device if you find that it is damaged in any way.

• Only use the power supply provided by the manufacturer.

• When not in use for long periods, disconnect the power supply from the mains.

• Do not at mpt to repair this device or take apart under any circumstances, as this will invalidate your te

warranty.

This product is classed as Electrical or Electronic equipment an should not be disposed with other household or commercial waste at d

the end of its useful life. The goods must be disposed of according to your local council guidelines.

Errors and omissions excepted.

Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
