4K HDMI Video Capture Card

Item ref: .836UK 128

U r Manual se

Application diagram:

128.836UK User Manual

A handy device for capturing both HDMI video and audio signals and sending them to

computers and smart devices for preview and storage. Simple plug and play operation

requires no additional drivers and is compatible with various acquisition software such

as VLC, OBS and Amcap. With a maximum input resolution of 3840×2160@30Hz and

output resolution of 1920×1080@30Hz this compact unit is ideal for transferring

camcorder or action cam footage, video games, live streams or office meetings to

hard disk or flash media.

Max. Resolution

Video Format

Video Output

Audio Format

Max. Cable Length

Max. working current

Operating System Compatibility

Dimensions

Weight

Input: 4K@30Hz, Output: 1080p@30Hz

8/10/12bit Deep colour

YUV, JPEG

L-PCM

≤15m, AWG26 HDMI standard cable

0.4A/5VDC

Windows, Android and MAC

64x28x13mm

22g

Technical specifications:

128.836UK User Manual

* Insert the video capture card into an available USB port on your PC or laptop and

wait for the default device driver “USB Video” to be installed.

* Connect a good quality HDMI cable between your source device and the HDMI

video capture card, the max cable length is 15 meters.

* Open your chosen piece of acquisition software and select “add a new Source device”.

* From the list of available options select “Video Capture Device” or “USB Video”.

* You should now be able to review and record the video and audio signals entering

the capture card from your source device.

* Please refer to the user instructions for your chosen acquisition software if you

cannot carry out the above setup procedure correctly.

* The minimum specification requirements for your PC or notebook are as follows:NOTE:

CPU: PC - i5-3400 or above, Notebook - i7-3537U 2.0GHZ or above

Graphics card: PC - NVIDIA GT630 or above, Notebook - NVIDIA GT735M or above

4GB RAMSystem memory:

Technical specifications:

* For reasons of electrical safety this device must never be immersed in water,

exposed to damp conditions or excessive force.

* Please do not use this device if you find that it is damaged in any way.

* Do not attempt to repair this device or take apart under any circumstances, as this

will invalidate your warranty.

This product is classed as Electrical or Electronic equipment and should not be

disposed with other household or commercial waste at the end of its useful life.

The goods must be disposed of according to your local council guidelines.

AVSL (Europe) Ltd, Unit 3D North Point House,

North Point Bus. Park, New Mallow Road, Cork, Ireland.

Taylor Road, Trafford Park, Manchester. M41 7JQ.

Warning:

Errors and omissions excepted.
