INSTALLATION INSTRUCTIONS FOR PART AFSI-01
METRA. The World’s best kits.™metraonline.com1-800-221-0932 © COPYRIGHT 2004-2011 METRA ELECTRONICS CORPORATION
REV. 11/14/2013 INSTAFSI-01
CAUTION. Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE. Refer to the instructions included with the
aftermarket radio.
• Provides accessory (12-volt 10-amp)
• Retains R.A.P. (retained accessory power)
• Used in non-amplified systems
• For standard sound systems with stand-alone subwoofer,
use part number 70-5522 along with the AFSI-01
• For SONY/THX amplified systems, use part numbers AX-ADBOX2 and AX-ADFD01
• Provides NAV outputs (parking brake, reverse, mute, V.S.S.)
• OE Bluetooth retention
• Retains SYNC
• Adjustable gain control for SYNC
• High level speaker input
• Micro “B” USB updatable
KIT FEATURES
• Cutting tool • Crimping tool • Tape • Connectors
(example butt-connectors, bell caps, etc.)
TOOLS REQUIRED
Ford SYNC retention
interface 2008-up
APPLICATIONS
See inside front cover
• AFSI-01 Interface • AXXESS 16-pin harness with
stripped leads • AXXESS 22-pin to Ford 24-pin and
16-pin harness • LCD screen
INTERFACE COMPONENTS
AFSI-01
Applications
FORD
Econoline 2010-up
Edge 2008-2010
Escape 2009-2012
Expedition 2009-up
Explorer 2008-2010
Explorer Sport Trac 2008-2010
F-250/350/450/550 2009-up
Flex 2008-2012
Fusion 2008-2012
Taurus 2008-2009
Taurus X 2008-2009
LINCOLN
MKX 2008-2010
MKZ 2008-2009
MERCURY
Milan 2008-2011
Mountaineer 2008-2010
Sable 2008-2009
From the AXXESS 16-pin harness
• Connect the wires to the ignition/accessory wire of the aftermarket radio.Red
• Connect the wire to the illumination wire of the aftermarket radio. If the Orange/White
aftermarket radio does not have an illumination wire, tape off the wire.Orange/White
• Connect the wire to the amp turn on wire of the aftermarket radio (note, wire Blue/White
must be connected even if there isn’t an amp in the vehicle).
• Connect the wire to the mute wire of the aftermarket radio. If the aftermarket radio Brown
does not have a Mute wire, tape up the wire (note, if the mute wire is not connected Brown
the radio will turn off when OnStar is active).
• Connect the wire to the left front positive speaker output of the aftermarket radioWhite
• Connect the wire to the left front negative speaker output of the aftermarket radio.White/Black
• Connect the wire to the right front positive speaker output of the aftermarket radio.Gray
• Connect the wire to the right front negative speaker output of the aftermarket radio.Gray/Black
Tape up the following wires as they will not be used in this application:
Installing the Interface
• wireGreen
• wireGreen/Black
• wirePurple
• wirePurple/Black
AFSI-01
The following wires are for the aftermarket radios that have navigation built in.
• Connect the wire to the parking brake wire of the aftermarket Light Green
navigation radio.
• Connect the wire to the VSS or speed sense wire of the aftermarket Blue/Pink
navigation radio.
• Connect the wire to the reverse wire of the aftermarket Green/Purple
navigation radio.
From the 22-pin harness
The DIN plug is to be connected to the included XIA-LCD screen.
From the 24-pin harness
• Connect the wire to the ground wire of the aftermarket radio.Black
• Connect the Yellow wire to the constant wire of the aftermarket radio.
• Connect the wire to the antenna turn-on of the aftermarket radio.Blue
• Disregard the wire. This wire is not used in this application. Blue/White
• Connect the wire to the right rear positive wire of the aftermarket radio.Violet
Installing the Interface
• Connect the wire to the right rear negative wire of the Violet/Black
aftermarket radio.
• Connect the wire to the left rear positive wire of the aftermarket radio.Green
• Connect the wire to the left rear negative wire of the Green/Black
aftermarket radio.
From the Ford 16-pin harness
• Connect the RSE/SYNC/SAT RCA’s to the AUX in on the aftermarket radio.
• Disregard the labeling on the RCA. This interface only retains SYNC.
Installing the AFSI-01
1. With all the connections completed, plug the 22 and 16-pin harnesses
into the AFSI-01
2. Plug the 24, and 16-pin Ford harness into the vehicle side harness, and plug the
aftermarket radio harness into the aftermarket radio.
3. Reconnect the negative battery terminal.
4. Initialize the interface by cycling the key by turning the ignition on for 30
seconds then back off, and then back on again to test the radio.
