The GMRSAV is designed to provide an audio/video input to the

OEM overhead video screen from the aftermarket radio, and provide

the audio/video input from the rear seat control panel to the

aftermarket radio.

GMRSAV

INTRODUCTION

BUICK

Enclave 2008-up

CADILLAC

Escalade/ESV/EXT 2007-2011

SRX 2007-2009

CHEVROLET

Avalanche 2007-2011

Avalanche without NAV 2012-up

Silverado 2007-2011

Silverado without NAV 2012-2013

Suburban 2007-2011

Suburban without NAV 2012-up

Tahoe 2007-2011

Tahoe without NAV 2012-up

Traverse 2009-up

GMC

Acadia 2007-up

Sierra 2007-2013

Yukon 2007-2011

Yukon without NAV 2012-up

HUMMER

H2 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

SUZUKI

XL-7 2007-2009

APPLICATIONS

INTERFACE COMPONENTS

• 16-pin GMLAN RSE harness

TOOLS REQUIRED

• Cutting tool • Tape • Crimping tool

• Connectors (i.e. butt-connectors, bell caps, etc.)

INSTALLATION INSTRUCTIONS

Important: Before beginning any of the following, disconnect the negative

battery terminal to prevent an accidental short circuit.

From the 16-pin harness

• Connect the “From rear A/V input” RCAs to the aftermarket radios

audio/video input. Plug Yellow in to video-in, Red to right audio-in,

and White to left audio-in.

• Connect the “To overhead screen” RCAs to the aftermarket radios

audio/video output. Plug Yellow in to video-out, Red to right audio-out,

and White to left audio-out.

• Connect the Black with the ring terminal to ground.

The GMRSAV is designed to provide an audio/video input to the

OEM overhead video screen from the aftermarket radio, and provide

the audio/video input from the rear seat control panel to the

aftermarket radio.

GMRSAV

INTRODUCTION

BUICK

Enclave 2008-up

CADILLAC

Escalade/ESV/EXT 2007-2011

SRX 2007-2009

CHEVROLET

Avalanche 2007-2011

Avalanche without NAV2012-up

Silverado 2007-2011

Silverado without NAV2012-2013

Suburban 2007-2011

Suburban without NAV2012-up

Tahoe 2007-2011

Tahoe without NAV2012-up

Traverse 2009-up

GMC

Acadia 2007-up

Sierra 2007-2013

Yukon 2007-2011

Yukon without NAV2012-up

HUMMER

H2 2008-2009

PONTIAC

Torrent 2007-2009

SATURN

Outlook 2007-2010

SUZUKI

XL-7 2007-2009

APPLICATIONS

INTERFACE COMPONENTS

• 16-pin GMLAN RSE harness

TOOLS REQUIRED

• Cutting tool • Tape • Crimping tool

• Connectors (i.e.butt-connectors,bell caps,etc.)

INSTALLATION INSTRUCTIONS

Important: Before beginning any of the following, disconnect the negative

battery terminal to prevent an accidental short circuit.

From the 16-pin harness

• Connect the “From rear A/V input”RCAs to the aftermarket radios

audio/video input. Plug Yellow in to video-in,Red to right audio-in,

and White to left audio-in.

• Connect the “To overhead screen”RCAs to the aftermarket radios

audio/video output. Plug Yellow in to video-out,Red to right audio-out,

and White to left audio-out.

• Connect the Black with the ring terminal to ground.
