Sida 1/8
AXDSPX-BMWM25
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 5/10/25 INSTAXDSPX-BMWM25
MOST25
®
/DSP Data Interface with Amplifier
Bypass Harness
Fits Select BMW Models 2010-2020
INTERFACE COMPONENTS
• AXDSPX-BMWM25 interface • AXDSPX-BMWM25 harness
• AXBK-1 Bass Knob • LD-MOSTCAP •BMWM25
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape
• Wire cutter • Zip-ties
• Multimeter • Tone generator
TABLE OF CONTENTS
Connections: Adding Amp & Sub .........................2
Installing the Fiber Optic Cable.............................3
Installation .........................................................4-5
Quick Setup Steps: AX-DSP-XL App ...................... 6
Specifications ..........................................................7
Troubleshooting/LED Feedback ............................ 8
Speaker Assignment QR Code .............................. 8
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal before
installing this product. Ensure that all installation
connections, especially the air bag indicator lights, are
plugged in before reconnecting the battery or cycling
the ignition to test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
For Dash Disassembly Instructions, refer to
metraonline.com. Enter the year, make, and
model of the vehicle in the Vehicle Fit Guide
for Radio Install kits.
APPLICATIONS
Visit Axxessinterfaces.com for current application list
iOS
®
12.1 or higher
Download the AX-DSP-XL App
Android™ 9 or higher
• Designed for MOST
®
amplified systems
• Selectable 31-band Graphic EQ or 5-band parametric EQ on each
channel with high pass, low pass, and bandpass filters
• 6 inputs and 10 individually assignable outputs
• Selectable slope (12, 24, 36, or 48db per octave)
• Selectable Graphic or Parametric EQ
• Independent equalization on each of the 10 outputs
• Each channel can be delayed independently up to 10 ms
• Clipping detection and limiting circuits
• Bass knob included
• Settings adjusted wirelessly in the free AX-DSP-XL app available
for smartphones and tablets
• To be used with factory radios
• Read, write, and store configurations for future recall
• Password protect feature available in the app
• Micro “B” USB updatable
FEATURES & SPECIFICATIONS
2
CONNECTIONS: ADDING A FULL-RANGE AMP & SUB TO A FACTORY SYSTEM
An SPDT relay, Metra part number
E-123, must be used if the amp turn-on
current of all amps exceed 1-amp.
Factory Amp
(must be removed)
RCA Jacks
(sold separately)
Speaker Assignment QR Code
located on page 10 of instructions
AXBK-1
CH 6
CH 10
CH 7
CH 8
CH 9
Factory Amp Harness
AXBK-1
Not Used
OR
A
A
B
PWR
CONNECTION TYPE
Speaker Assignment QR Code
located on page 10 of instructions
PWR CONNECTION TYPE
Type: A
1 Series
2 Series
Type: B
3-7 Series
X Series
RCA Jacks
(sold separately)
