IMPORTANT:
This booklet should be left with the user after
installation and demonstration
Installation and User Guide
V 8.5/9.5KWERVE
2
1 – Pack Contents 3
2 – Installation Check List 3
3 – Important Safety Information 4
4 – General Installation Layout Guide 5
5 – Important Installation Information 6
6 – Fixing the Shower to the Wall 6
7 – Product Positioning Guide 7
8 – Plumbing Connections 8
9 – Electrical Connections 9-10
10 – Fitting the Front Cover 10
11 – Riser Rail Fitting Instructions 11
12 – Commissioning the Shower 12
13 – Troubleshooting Checklist for the Installer 13
1 – Important Safety Information 14
2 – Operating the Shower 15
3 – How Your Shower Works 16
4 – Routine Maintenance 16
5 – Troubleshooting and FAQs 17
6 – Troubleshooting Checklist for the Installer 18
7 – Energy Related Product Directive (ErP) 19
User Guide
Installation Guide
IMPORTANT: This appliance can be used by children aged from 3
years and above and persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
The shower spray head MUST be cleaned regularly to remove
scale and debris. The frequency of the cleaning will vary according
to the local water quality. If the water outlet temperature becomes
hot and you are unable to obtain cooler water, immediately check
the shower handset for blockage. See User Guide Section 4 for
cleaning instructions.
Do not operate shower if frozen, or suspected of being frozen. It
must thaw out before using.
Contents
Installation Guide
3
Shower Unit
Shower Handset
Riser Rail Tube
Riser Rail Brackets x 2
Riser Rail Height Adjuster
Flexible Shower Hose
Soap Dish
Screw Pack
Installation and User Instructions
Please make sure ALL components are included before starting the installation.
Installation Guide
1. Pack Contents
2. Installation Check List
Check that the water supply will satisfy requirements
Check that water & cable entry points of the unit meet requirements
Check that the electric supply will satisfy requirements
Select a suitable position for the shower
Follow plumbing installation section
Follow electrical installation section
Fit to the wall & connect the shower supplies
Commission the shower in the way described
Fit the front cover & aligning the controls
Familiarise yourself with the user operating instructions
