Sida 1/8
INSTALLATION
DKPS-2A
POWER SUPPLY / CHARGER FOR ACCESS CONTROL AND EGRESS DOORS
ISDKPS-2
8.
9.
10.
11.
12.
13.
14.
15.
16.
17.
19.
20.
21.
22.
This power supply should be installed in compliance with the National Electrical
Code(NFPA 70) CSA C22.1, Canadian Electrical Code, Part 1 and all applicable
Local Codes. Installation to be performed by suitably qualified technical
personnel.
Description
The DKPS-2A is a power supply/charger that supplies a total of 2.5 amps
nominal continuous supply current at nominal 12/24VDC outputs. There are
4 outputs for Magnetic lock or door strike each with electronic over-current
protection @ 2 Amp. It is installed in a large mild steel metal enclosure capable
of accommodating two 7AH or 12AH lead-acid rechargeable batteries
. These are
monitored Power Supplies for use in Access Control and Egress Doors.
Listed under UL294, CAN/ULC-60839-11-1 and CAN/ULC-S533.
Battery load test every 48hr.
Battery Charger test every 48hr.
Battery Reversal protection.
Low Battery indication at 11.40/22.80 Volts
Low Battery disconnect at 10.10/20.30 Volts.
Automatic switch over to stand-by battery upon AC Failure.
Common “Batt.Fault” CMOS relay for all battery and charger fault.
CMOS relay output for AC failure within 60 seconds.
LEDs display on enclosure door (LEDs, Green, Yellow).
Common “Out Fault” CMOS relay for DC failure on any of the 4 outputs.
Battery charging leads included.
Board Dimension: 195mm x 110mm
Enclosure Dimension: 338mm x 448mm x 110mm.
AC input indication by Green LED. (LED on when AC is present).
1. Input = 100-240VAC, 50-60Hz. 2.4A Max draw.
2. Output 2.5 Amps continuous supply current at Nominal 12/24 VDC
controlled outputs and one auxiliary output.
3. 4 Magnetic Lock or 4 Strikes outputs each, with electronic over-current
protection set at 2 Amp.
4. Built-in dedicated charger for sealed lead acid or gel cell type batteries.
5. Maximum battery charging current 1 Amps
6. Yellow LED for Battery Fault indication including charger failure monitor.
7. Battery presence detection within 10 seconds.
PART NO:DM2000 Ver.02
General Specifications:
© 2020 dormakaba Canada Inc
www.dormakaba.us • Phone: 1.800.265.6630 • Fax: 1.800.482.9795 • E-mail: sales_RCI@dormakaba.com
R01-20GB
1
