Flash 192
SPECIFICATIONS:
Model: Flash 192
Voltage: 100V-230V 50/60Hz
LEDs: 192 x 0.06W
Beam Angle: 60 Degrees
Power Consumption: 15W
Weight: 3.59lbs./ 1.63kgs.
Size: 11”(L) x 7.87”(W) x
2.36”(H) (w/o Bracket)
11”(L) x 7.87”(W) x
7.87”(H) (w/ Bracket)
Fuse: 1 Amp
Power Cord Daisy Chain: 25 Fixtures Max.
Working Position: Any Safe position
Duty Cycle: None
DMX Channels: 4 DMX Channels
Colors: White
Warranty: 1 Year
CAUTION! Please read and under-
stand these instructions before
installing or operating this unit.
Operating Instructions:
The Flash 192 has been tested at the factory, there is no assembly required. The unit is ready to be
plugged into a power outlet. This unit is a 4 channel DMX intelligent strobe. It has 3 operating mode;
Manual mode, Sound Active, or DMX mode. The Flash 192 can be used as a stand alone unit or in a
master-slave conguration.
Fuse Replacement: Disconnect the unit from its power source. Remove the power cord from the
unit. Once the cord has been removed, you will nd that the fuse holder is located inside the power
socket. Insert a flat-head screw driver into the power socket and gently pry out the fuse holder.
Remove the bad fuse and replace with a new one. The fuse holder also has a holder for a spare fuse.
Power Cord Daisy Chaining: With this feature you can connect the xtures to one another using the
IEC input and output sockets. The quantity that can be connected is 25 xtures maximum. After 25
xtures you will need to use a new power outlet. They must be the same xtures. DO NOT mix xtures.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
Caution! Never open unit when in use. Always
disconnect main power before replacing fuse.
Remember to always replace with the exact same
type fuse.
DMX Mode:
Operating through a DMX controller give the user the freedom to create own programs tailored s their
to their own individual needs. The Flash 192 has 4 DMX channels; Dimming, Strobing, Sound Active,
and Fading.
1. This function will allow you to control each individual xture’s traits with a standard DMX 512
controller.
2. To run your fixture in DMX mode press the UP or DOWN buttons until “AXXX” is displayed. “XXX”
represents the current displayed address. Use the UP or DOWN buttons to select your desired
DMX address.
3. After you have chosen your desired DMX address plug in the xture via the XLR connections to
any standard DMX controller.
Auto Mode:
1. Plug the xture in and press the UP or DOWN buttons until “AUdi” is displayed, and press
ENTER. After you press ENTER, “Pr.01” will be displayed.
2. Press the ENTER button again to access the strobe speed. After pressing ENTER, “SP.XX” will be
displayed, use the UP and DOWN buttons to adjust the strobe speed.
Sound Active Mode:
1. Plug the xture in and press the UP or DOWN buttons until “Auto” is displayed, and press
ENTER. After you press ENTER, “Pr.01” will be displayed.
2. Press the ENTER button again to access the strobe speed. After pressing ENTER, “SP.XX” will be
displayed, use the UP and DOWN buttons to adjust the strobe speed.
Default:
1. Plug the xture in and press the UP or DOWN buttons until “dEFA” is displayed, and press
ENTER.
2. Press the UP or DOWN buttons so that YES is displayed, and press ENTER. The unit will now
revert back to the default settings.
Master-Slave Conguration:
1. Set the “Master” unit to your desired operating mode, then connect the “Slave” units.
©Eliminator® Los Angeles, CA. - www.EliminatorLighting.com
1 Year Limited Warranty: Eliminator Lighting warranty is valid from the date of purchase. Our
1 year limited warranty covers manufacturing defects only. Serial number, place of purchase with
dated valid receipt must be submitted at time of service. Eliminator Lighting warranty does not cover
items or parts prone to wear and tear: lamps, fuses, brushes and belts. Eliminator Lighting warranty
is only valid with-in the United States.
DMX TRAITS: 4 CHANNELS
CHANNEL 1: DIMMER/STROBE CHANNEL 3: SOUND ACTIVE
1 - 10 = ON 0-10 = NO FUNCTION
11 - 20 = BLACKOUT 11-255 = SOUND ACTIVE STROBING
21 - 255 = DIMMER 0%-100%
CHANNEL 2: STROBE CHANNEL 4: FADING
0 - 10 = ON 0-10 = NO FUNCTION
11 - 255 = STROBING SLOW - FAST 11-255 = FADING SLOW - FAST
Produktspecifikationer
