1
EX
EX
EX
EXEX-
-
-
--
6300MM / SM
6300MM / SM
6300MM / SM
6300MM / SM6300MM / SM
RS- 232 to Fiber Optic Converter
1. Introduction
Thank you for purchasing this RS232 to Fiber Optic Converter. It is designed to
extend RS232 signals over optical fiber. It provides the most versatile connection
possible between any asynchronous RS232 equipments using fiber optic cable.
The optical fiber isolates the data signals from ground potential, ground loops and
provides EMI/RFI protection. There are 2 models, singlemode and multimode. --
The multimode converter is used to extend serial transmission distance up to -
2Km. The singlemodel converter extends up to 40Km. -
Features:
Provides 1 RS232 Port over Fiber Optic
Provides 1 RS232 DB9 Male Connector
Fiber Optic: SC, Multi Mode, 850nm, Duplex
SC, Single Mode, 1310nm, Duplex
RS232 Baud Rate from 300bps to 921.6Kbps
Protects Against Electrical Interference or Chemical Corrosion
Extends RS232 Transmission up to 2Km, multimode (or 40Km, singlemode--
Distance
15KV ESD Protection for Serial Port Signals
Powered by Serial Connector or External DC Jack
Provides both Wall Mounting and DIN RAIL Kits
Compact Size
2. Layout
RS232 DB9 male connector
Fiber TX LED
Fiber RX LED
DIN RAI Mounting Kit
12V DC Jack
Fiber Optic
Transceiver
