Because there are large dierences between PC’s, we can give you only a general installa-

tion guide for the EX-1316HMV. Please refer your computer’s reference manual whenever

in doubt.

1. Connect the USB cable to the USB B-Port of the module an lock the screw.

2. Now connect the other end from the USB cable (A-Plug) to the A-Port at your PC.

HARDWARE INSTALLATION:

6 5

EXEXEX

-1316HMV1316HMV1316HMV

EnglishEnglishEnglish

EXEXEX

-1316HMV1316HMV1316HMV

EnglishEnglishEnglish

Die EX-1316HMV ist ein Modul zur Umsetzung von USB 2.0 auf sechzehn RS-232

Schnittstellen mit FIFO 16C550 Ports für den Anschluss von High Speed Seriellen RS-

232 Peripherie Geräten (z.B. Modem, Plotter usw.). Die USB Module sind Hot Plug &

Play fähig. Für die Einstellungen der I/O Adressen und Interrupts sind keine Jumper und

Einstellungen notwendig. Sie werden vom System BIOS und beim installieren des

Betriebssystems automatisch vorgenommen. Die EX-1316HMV ist zusätzlich mit ver-

schraubbarem USB-Anschluss ausgerüstet.

BESCHREIBUNG & TECHNISCHE DATEN:

AUFBAU:

Kompatibilität: USB 2.0 Anschluss

Betriebssysteme: WIN 9.x/ ME/ 2000/ XP/ Server 200xx/ Vista/ 7/ 8, Linux, MAC

Anschlüsse: 16x 9 Pin D-Sub Stecker, 1x USB B-Buchse, 1x 12V Buchse,

1x 7V bis 40V Power Anschluss (Terminal Block)

Lieferumfang: EX-1316HMV, Treiber CD, Anleitung, USB Kabel

Zertikate:

CECE

CE / FCC / RoHS / WEEE DE97424562 / WHQL

DRIVER INSTALLATION:

Betriebs LED

12V Buchse für Netzteil

USB B-Buchse

PC-Anschluss

(Verschraubbar)

CLEANING:

For cleaning please use only a dry u less cloth and remove the dirt with gently pres-

sure. In the area of the connectors please make sure that no bres from the cloth re-

main in the connectors. Attention! Never use a moist or wet cloth for cleaning!

BedienungsanleitungBedienungsanleitung

Vers. 1.2 / 05.06.13

Windows XP/ Vista/ 2000/ Server 200x/ 7/ 8 (32&64-Bit) :

Windows will recognize a new and open the hardware assistant. “FT232R USB UART“

Please choose manual installation and put the driver CD into your CD-Rom drive. Enter

the Path

"D:\USB_to_IO\FTDI\(32_64bit)Win7_8_XP_Vista_2008_2008R2_2003_2000”.

into the box for the Path/Source and click at . Now Windows search for >next/continue<

the drivers in the specied directory. Follow the hardware assistant and nish the instal-

lation. If Windows recognizes other new devices repeat the above described steps.

Attention! Restart Windows in any case after installing the drivers.

CHECK THE INSTALLED DRIVER:

Click at <> < then enter and click at . In the windows Start Run “compmgmt.msc“ >OK<

that open select Under you should nd >Device Manager<. ”Ports (COM and LPT)“

one more new as sample (COM5). If you see this or similar entries "USB Serial Port„

the module is installed correctly.

INSTALL THE PERIPHERAL DEVICE:

The speed from the serial ports can be set to the maximum baud rate of 115.2Kbaud.

With double click select for example < >Device manager< > USB Serial Port (COM5) .

Now you can select the dierent settings of baud rate, stop/start-bits etc. This setting

you can use also for the other COM ports.

DRIVER INSTALLATION:

Windows 98/ 98SE/ ME:

Windows will recognize a new and open the hardware assistant. “FT232R USB UART“

Please choose manual installation and put the driver CD into your CD-Rom drive (as

sample D:) . Now enter the Path into the box for the “D:\USB_to_IO\FTDI\Win98_ME”

Path/Source and click at . Now Windows search for the drivers in the >next/continue<

specied directory. Follow the hardware assistant and nish the installation. If Windows

recognizes other new devices repeat the above described steps. Restart Attention!

Windows in any case after installing the drivers.

CHECK THE INSTALLED DRIVER:

Click at <> < then enter and click at . In the windows Start Run “compmgmt.msc“ >OK<

that open select Under you should nd >Device Manager<. ”Ports (COM and LPT)“

one more new as sample (COM3). If you see this or similar entries "USB Serial Port„

the module is installed correctly.

CHANGE PORT NUMBER:

If you like to change the port number for example COM 3 to COM 5, open the >Device

Manager< click at >COM3<, >Settings< and then >Advance<. There you can change

between COM 3 to 256.

LINUX:

There are drivers available for Linux. The drivers are located in the folder

“D:\USB_to_IO\FTDI\Linux x86_64“ on the driver CD. They are supported by the most

versions of Linux. Because each individual distribution and kernel version of Linux is

dierent, sadly we cant provide a installation instruction. Please refer to the installation

manual for standard IO ports from your Linux version !

MAC:

There are drivers available for MAC. The drivers are located in the folder

“D:\USB_to_IO\FTDI\MAC OSX or Mac_OS_9_8“ on the driver CD. They are support-

ed by the most versions of MAC OS. Because each individual version of MAC OS is

dierent, sadly we cant provide a installation instruction. Please refer to the installation

manual for standard IO ports from your MAC OS version !

Vorderseite:

S1-S16: 9 Pin Seriell RS-232 Stecker

Metallbügel zum Einbau in ein 19“ Rack

+7V ~ 40V

Power Anschluss

Rückseite:

Installation auf einer Trägerschiene:

JUMPER SETTING & CONNECTORS :

ATTENTION !!!

Use only the original

power supply !!!

12 Volt Connector:

DB 9M:

Pin Signal Pin Signal Pin Signal

1 CDC 4 DTR 7 RTS

2 RXD 5 GROUND 8 CTS

3 TXD 6 DSR 9 RI

Serial 9 Pin male connector

USB B-Connector:

Attention!

Never plug in with

force or in wrong

direction.

+7V ~ 40V Terminal Block:

+7V ~ 40V

GND (Ground)

USB 2.0 B-Connector

Pin Signal Pin Signal

1 VCC 3 DATA+

2 DATA- 4 GND

Produktspecifikationer

Varumärke:	EXSYS
Kategori:	ej kategoriserat
Modell:	EX-1316HMV
Vikt:	1000 g
Bredd:	336 mm
Djup:	68 mm
Höjd:	43 mm
Certifiering:	CE, FCC
Värdgränssnitt:	USB
Storlek:	19 "
Seriellt gränssnitt:	RS-232
Produktens färg:	Svart
Windows-operativsystem som stöds:	Ja
Mac-operativsystem som stöds:	Ja
Temperatur vid drift:	0 - 55 ° C
Temperaturintervall (förvaring):	-30 - 75 ° C
Intervall för relativ operativ luftfuktighet:	5 - 95 %
Seriella portar:	16
Hållbarhetscertifiering:	RoHS
Anslutningsteknologi:	Kabel
Linux operativsystem som stöds:	Ja
Intern:	Nej
Kretsar:	FTDI
Mac-kompatibel:	Ja
Utgränssnittet:	Serial
