Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 5/28/25 INST95-6559B
INSTALLATION INSTRUCTIONS
95-6559B
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product.
Ensure that all installation connections,
especially the air bag indicator lights, are
plugged in before reconnecting the battery
or cycling the ignition to test this product.
NOTE: Refer also to the instructions included
with the aftermarket accessory before
installing this device.
KIT FEATURES
KIT COMPONENTS
• A) Radio trim panel • B) OLED display and buttons • C) Radio brackets • D) Panel clip brackets (4) • E) Back panel • F) #4 x 3/8” Phillips screws (12)
• G) Panel clips (4) • H) Separate interface buttons: blanks (5) and with graphics (5) (not shown) • I) Interface, harnessing and antenna adapter (not shown)
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Socket wrench
TABLE OF CONTENTS
Dash Disassembly...................................................2
Kit Preparation....................................................3-5
Dash Preparation....................................................6
Kit Assembly......................................................7, 19
Axxess Interface Installation............................8-18
WIRING & ANTENNA CONNECTIONS
Wiring Harness & Antenna Adapter: Included
Radio Replacement Kit Fits Select Dodge
Durango Models
(With factory 4” screen)
2014-2020
A B
F G
C D E
Visit MetraOnline.com for more detailed information about
the product and up-to-date vehicle specific applications
• Retains factory climate control
buttons and adds factory-style hard
buttons with laser etched graphics
to retain and control functions
• Built-in OLED screen displays the
visual status of climate functions
such as temperature, fan speed, and
vent mode that were displayed on
the factory screen
• Retains steering wheel functionality
• Painted to scratch-resistant matte
black with chrome accents
• ISO DIN radio provision with pocket
sold separately (88-00-9004)
386.257.1187
|
MetraOnline.com
2
DASH DISASSEMBLY
Note: Before removing the factory radio,
check for features such as heated seat,
vented seat and heated steering wheel.
Buttons have been included for vehicles with
those options, and blank buttons have been
included for vehicles without those options.
See installation section of this manual for
more information.
1. Using the panel removal tool, gently
unclip, unplug, and remove the climate
control panel. (Figure A)
2. Remove (4) 9/32" screws securing the
radio/display screen, and then unplug
and remove. (Figure B)
3. Remove (3) 5.5mm screws securing the
black control module in the sub-dash,
and then relocate lower to allow
clearance for the aftermarket radio.
(Figure C)
Continue to Kit Preparation
(Figure A)
(Figure B)
(Figure C)
