BHM

12/3/13

NTV-DOC 150

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

1 | P a g e

3950 NW 120th Ave, Coral Springs, FL 33 TEL 561-955-9770 FAX 561-955-9760 065

www.nav-tv.com info@nav-tv.com

MY-CUE-Kit

NTV-KIT 457

Overview

The -CUE Kit allows the user to add up to 3 audio/video inputs and a backup camera input to MY

the factory media screen in select GM vehicles equipped with either the or media MYLINK CUE

systems. This kit has a dedicated rear view camera input, 3 composite (RCA) audio/video inputs,

an RGB input and an AV output with AV switching. Audio integraon requires that the vehicle

have a factory audio input.

Kit Contents

AV Input Harness

Power/CAN Harness

LVDS Video cable

MY-CUE Interface

Remote

RGB Input cable

Input Toggle Switch

IR Eye Harness

BHM

12/3/13

NTV-DOC 150

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

2 | P a g e

Interface Connectors

Dip Switch Sengs* Congure prior to installaon

Dip SW:

Enables

RGB

Enables

N/A

Leave up

N/A

Leave up

Factory or

no Rev-Cam

N/A

DOWN

Skips

RGB

Skips

N/A

Acvates

aermarket

Rev-Cam

N/A

Leave

down

AV IN/OUT

RGB INPUT

Rear Camera Power

Power/CAN

Dip Switches

Status LEDs

*Note: If the dip switches are not congured prior to

installaon you must remove power to the unit prior to

making adjustments to the dip switches. When power is

reconnected aer the dip switch adjustment the new

sengs will be stored into memory.

LCD IN/OUT

(LVDS Cable)

BHM

12/3/13

NTV-DOC 150

Agreement End user agrees to use this product in compliance with all State and Federal laws. NAV-TV Corp. would not be held liable for :

misuse of its product. If you do not agree, please discontinue use immediately and return product to place of purchase. This product is

intended for off-road use and passenger entertainment only.

3 | P a g e

Installaon for GM trucks and notes for all other vehicles

THIS INTERFACE INSTALLS AT THE HMI MODULE, AT THE SCREEN! THE HMI MODULE IS A NOT

BLACK PLASTIC BOX SHOWN IN STEP 3 OF THE NEXT PAGE.

1. GM trucks only: Remove the glove box, the HMI module is located behind it (black box

with connectors). Remove (2x) Torx t15 screws:

2. GM trucks only: Underneath the glove box you’ll nd (2x) more addional Torx T15

screws ring upwards. Remove these and pull the glove box free from the dash (all that

remain are clips).

Vehicle

HMI Locaon

Cadillac ATS/CTS

Directly Below glove compartment

Cadillac SRX

Below/behind glove compartment

Corvee

Driver’s kick

GM Truck

Behind glove compartment

This chart will be updated as informaon is provided.
