User Manual

Features

·Small and lightweight 3500-lumen LED Flashlight

·Utilizes 4 x CREE XP-L HI V3 LEDs

·Integrated multi-function OLED display

·Incorporates Precision Digital Optics Technology (PDOT)

Maximum intensity of 124,000cd

Beam distance up to 704 meters

·Thermal protection circuit prevents overheating

·Compatible with both 18650 Li-ion and CR123 batteries

·Intelligent charging circuit with voltage detection for safe and fast charging

·Exceptionally long runtime using 4 × 18650 Li-ion or 8 × CR123 batteries

·Capable of running on 1 × 18650 or 2 x CR123 batteries in emergency

situations

·Eight rapidly switchable brightness levels and modes to select from

·Innovative single button two-stage switch provides a user-friendly interface

(Chinese Patent: Z L201120062948.1)

·Toughened ultra-clear mineral glass with anti-reflective coating

·A power indicator built into the on/off switch indicates remaining battery power

(Chinese Patent: ZL201220057767.4)

·Stainless steel bezel ring protects core components from damage

·Constructed from aerospace-grade aluminum alloy

·HAIII military grade hard-anodized

·Waterproof in accordance with IPX-8 (two meters submersible)

Dimensions

Length: 142mm (5.6”)

Head diameter: 68 mm (2.68”)

Head side-length: 57mm (2.24”)

Tube diameter: 50mm (1.96”)

Weight: 442g (15.50oz) (without battery)

Accessories

Charger, quality holster, lanyard, and spare O-ring

Battery Options

Operating Instructions

Battery Installation

Unscrew the battery compartment, insert 4 × 18650 Li-ion or 8 × CR123

batteries with the positive (+) ends pointing toward the flashlight head. Tighten

the battery compartment. In special circumstances, TM26GT can run on as few

as one 18650 or two CR123 batteries.

Thanks for purchasing NITECORE!

Output & Runtime

NOTICE

The above data has been measured in accordance with the international

flashlight testing standards ANSI/NEMA FL1 using 4 x Nitecore 18650（3.7V

3400mAh) and 8 x Nitecore CR123 3V 1700mAh batteries under laboratory （

conditions. The data may vary during real-world use due to battery type,

individual usage habits and environmental factors.

The All-Round Flashlight Expert

TM 26GT

Note 1: Using less batteries than standard specification increases battery

output voltage, and may lead to potential dangers. Nitecore

recommends using this feature only when necessary and for short

periods of time. Please see point number 1 in the warning section

below.

Note 2: After installing batteries, “NITECORE” will be displayed on the OLED

screen for 2.5 seconds followed by battery voltage (accurate to

0.01V) for 4 seconds, after which the TM26GT will enter into standby

mode.

WARNING

1. Using less than 4 x 18650 or 8 x CR123 batteries can lead to turbo mode

malfunctioning, trigger the overload protection circuit in Li-ion batteries and

can even lead to explosion of batteries. As such Nitecore recommends that

this function is used with caution and only when necessary.

2. Insert batteries with the positive (+) ends pointing outward.

3. Do not mix rechargeable and non-rechargeable batteries.

4. Do not mix batteries of different types/brands.

5. Do not mix batteries of different charge levels.

6. Do not use lithium batteries without a protection circuit board.

7. This product does not support unprotected flat-top 18650 Li-ion batteries.

Please also ensure that all the 18650 batteries used in the TM26GT have a

button top configuration or they will not make contact with terminals in the

battery compartment. We recommend Nitecore 18650 batteries for the best

performance and reliability.

Charging the TM26GT

1. Connect the charging cable to the flashlight and the A/C power adapter to

the wall outlet as shown in the adjacent image. Fully charging four depleted

18650 batteries takes approximately 7 hours.

2. Under normal charging conditions, the on/off switch’s blue indicator light will

blink twice every second and the OLED screen will display the word

‘Charging...” together with battery voltage.

3. If a problem is detected during charging, the TM26GT will stop charging, the

blue indicator will blink rapidly and the OLED display will show the word

“ERROR”. This is usually caused by faulty or incorrectly inserted batteries.

4. When charging is complete, the blue indicator will remain on, and

“CHG.FINISHED” along with battery voltage will be displayed on the OLED

screen.

*Warning: Charge 18650 rechargeable Li-ion batteries only. Do not attempt to

charge non-rechargeable batteries, CR123 or RCR123 batteries.

TYPE

Nominal voltage

Compatible

Primary Lithium battery *

CR123 3V

Yes (Compatible but can

NOT be recharged)

Yes (Compatible but can

NOT be recharged)

18650 Rechargeable Li-ion battery

18650 3.7V

Yes (Recommended and

can be recharged)

Rechargeable Li-ion battery *

RCR123

3.7V

TURBO HIGH MID LOW

LUMENS

1700

LUMENS

3500

LUMENS

540

LUMENS

1h15min

h min30

h min15

h min45

LOWER

LUMENS

1000

750

704m

(Beam Distance)

124,000cd (Peak Beam Intensity)

IPX-8, 2m

(Waterproof AND Submersible)

1.5m (Impact Resistant)

8×CR123

4×18650
