Instruction Manual

NAVIGATION

BASIC OPERATION

Access the Main Menu

by pressing the Menu

Button.

Change Display

The -Menu offers Change Display

the , Full Screen Selected Screen

and view.Basic Screen

Program On/Off

In the you can Program-Menu

choose between or Program

Manual operation mode.

Navigate through the menu by press-

ing for lower and for higher – +

entries.

Enter the selected topic by press-

ing the Button or leave to select

the previous menu without any

changes by pressing

cancel.

1 2 3

ERT 50 Programmable room-thermostat

Change Profile

In the -Menu you Change Profile

can choose between the ,Family

Single Office Name 1, , and

Name 2 Profile.

Change Holiday

In the -Menu you Change Holiday

can make your holidays settings

and turn them or .On Off

Key Lock

By pressing the and button – +

for three seconds, a Key Lock can

be activated to protect the device

from failure operation.

Manual operation

By pressing the or buttons, – +

the manual operation mode will

be activated. Current Programs

will be overwritten until the next

daytime starts.

SALUS Controls GmbH D-63165 Mühlheim am Main Tel.: +49.(0)6108.825 85-0 Mail: info@salus-controls.de

Dieselstr. 34 Germany Fax: +49.(0 )6108 825 85-29 Web: www.salus-controls.de

WIRING PLAN

Terminal



Supply for temperature reduction

N Neutral wire

L 230 VAC supply

Switch output (actuator, terminal strip)

PROGRAM-MENU

Program Menu

To access the press program-menu

the or button, open the hatch and – +

press and at the same select cancel

time for three seconds.

Heat/Cool

Enter the -Menu to activate the Heat/Cool

Heat Cool or function of the device.

Control

Enter the -Menu to make changes on the Control

Span SetBack Frost Output VP, , *, and settings.

* Thermostat serves as protection against frost

and keeps temperature constant at 5°C.

Daytimes Time Family Single Office Name 1 Name 2

Mon - Fri

Eearly Morning

Morning

Noon

Afternoon

Evening

Night

06:00 - 08:00

08:00 - 12:00

12:00 - 14:00

14:00 - 18:00

18:00 - 23:00

23:00 - 06:00

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Sat - Sun

Eearly Morning

Morning

Noon

Afternoon

Evening

Night

06:00 - 08:00

08:00 - 12:00

12:00 - 14:00

14:00 - 18:00

18:00 - 23:00

23:00 - 06:00

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Comfort

Standard

Comfort

Standard

Comfort

Reduced

Basic Settings

Enter the -Menu to Basic Settings

adjust , and Date/Time Language

Maintenance settings.

Temp. Zones

Enter the Temp. Zones-Menu to adjust the temperatures of the Com-

fort Standard Reduced, and zones.

The three temperature zones can be allocated to the six day times.

If you modify a temperature zone, the temperature-settings within

the profiles will change as well. The zones are preinstalled with these

temeratures:

Comfort 24°C Standard 20°C Reduced 16°C

Purpose and correct use:

This standalone mounted electronic device

serves as a temperature control system only in

dry and closed living and office spaces. Clean

device only with a dry and soft cloth. Do not

use solvents or aggressive cleaning agents!

The manufacturer accepts no responsibility

for damage caused by non-observance of

these instructions.

Changing the batteries

2 x +AA Batteries

Do not dispose of batteries with

general household refuse. Please take

battery to municipal collection point

or dispose with trade waste.

Profile

Enter the -Menu to adjust the detailed settings of the , , , and Profiles.Profile Family Single Office Name 1 Name 2

You can adjust the profiles to your needs, by varying the 6 daytimes and allocate them new temerature zones. This

can be done for a single day or week and weekend. You can rename profiles and copy settings inside a profile and

from one profile to an other. In the following table, you can find the preinstalled settings:

DATA SPECIFICATION

Supply:

2 x Batteries Type AA (intern)

230V AC / 50Hz (extern)

Electronic switch output

Switching current max.: 10 (2) A

Number of actuators, max.: 5 units - 3W

Hysteresis: 0.5K

Protective class: IP 30

Dimensions W/H/D in mm: 75/130/30

Temperature range: 5°C - 30°C

Storage temperature: -25°C - 65°C
