For the :

DS47

XPC BIOS User Guide

Shuttle®

XPC Installation Guide

No part of this publication may be reproduced, transcribed, stored in a retrieval system,

translated into any language, or transmitted in any form or by any means such as electronic,

mechanical, magnetic, optical, chemical, photocopy, manual, or otherwise, without prior

written permission from Shuttle® Inc.

Other brands and product names used herein are for identification purposes only and may

be trademarks of their respective owners.

Disclaimer

Shuttle® Inc. shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

Shuttle® Inc. makes no representation or warranty regarding the contents of this ma-

nual. Information in this manual had been carefully checked for accuracy;however, no

guarantee is given as to the correctness of the contents. For continuing product improve-

ment, Shuttle® Inc. reserves the right to revise the manual or make changes to the speci-

fications of this product at any time without notice and obligation to any person or entity

regarding such change. The information contained in this manual is provided for general

use by customers.

This device complies to Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

1. This device may not cause harmful interference.

2. This device must withstand any background interference including those that may

cause undesired operation.

Trademarks

Shuttle is a registered trademark of Shuttle Inc.

Intel and Pentium are registered trademarks of Intel Corporation.

PS/2 is a registered trademark of IBM Corporation.

AWARD is a registered trademark of Award Software Inc.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

General Notice

Other brand and product names used herein are for identification purposes only and

may be trademarks of their respective owners.

Safety Information

Read the following precautions before setting up a Shuttle XPC.

Installation Notices

Do not place this device

underneath heavy loads

or in an unstable position.

Do not expose this device to high

levels of direct sunlight, high-

humidity or wet conditions.

Do not use or expose this device

around magnetic elds as magnetic

interference may affect the

performance of the device.

Do not block the air vents

this device or impede the

airow in any way.

Laser compliance statement

The optical disc drive in this server is a laser product. The drive's

classication label is lacated on the drive.

CLASS 1 LASER PRODUCT

CAUTION

：

NVISIBLE LASER RADIATION WHEN OPEN.

AVOID EXPOSURE TO BEAM.

CAUTION

Incorrectly replacing the battery may damage this computer. Replace only

with the same or equivalent as recommended by Shuttle. Disposal of used

batteries according to the manufacturer's instructions.

Produktspecifikationer

Varumärke:	Shuttle
Kategori:	Inte kategoriserad
Modell:	XPC DS47
Produkttyp:	Mini-PC, barebone
Vikt:	1430 g
Strömförsörjning:	100- 240V AC
LED-indikatorer:	HDD, Power
Processorfrekvens:	1.1 GHz
Processorfamilj:	Intel® Celeron®
Wi-Fi:	Ja
Ljudsystem:	HD
Antal HDMI-portar:	1
DVI-port:	Ja
Hörlursutgångar:	1
Certifiering:	FCC, CE, BSMI, C-Tick
Processor:	847
Maximalt internminne:	16 GB
Intel® Hyper Threading Technology (Intel® HT Technology):	Nej
Intel® AES nya instruktioner (Intel® AES-NI):	Nej
Idle stater:	Ja
Intel® 64:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Nej
Intel® Trusted Execution Technology:	Nej
Kompatibla operativsystem:	Windows 8, Windows 7, Windows XP, Linux
Ljudutgångskanaler:	5.1 kanaler
Säkerhet:	CB, BSMI, ETL, CCC
Intel® FDI-teknik:	Ja
Mini PCI Express-kortplatser:	2
Antal processorer som stöds:	1
Antal lagringsenheter som stöds:	1
Minnestyper som stöds:	DDR3-SDRAM
Antal minnesplatser:	2
Typ av minneskort:	SD, SDHC, SDXC
Produktens färg:	Svart
Inbyggd kortläsare:	Ja
processortillverkare:	Intel
Nätverksegenskaper:	Gigabit Ethernet, WLAN
Inbyggd processor:	Ja
Installerat operativsystem:	Nej
Antal LAN (RJ-45) anslutningar:	2
Produktstorlek (BxDxH):	39.5 x 200 x 165 mm
Temperatur vid drift:	0 - 40 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
processorsockel:	BGA 1023
Processorns kodnamn:	Sandy Bridge
Seriella portar:	2
Material, hölje:	Metall
Nätverksansluten (Ethernet):	Ja
På / av-knapp:	Ja
Antal USB 2.0 anslutningar:	4
Minnesplatser, typ:	SO-DIMM
Minnets hastigheter:	1066,1333 MHz
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	2
LAN-styrenhet:	Realtek RTL8111G
Moderkortets chipset:	Intel® NM70 Express
Processorkärnor:	2
Bluetooth:	Nej
Nätaggregatstyp:	AC/DC
Gränsssnitt för panelmontering:	75 x 75, 100 x 100 mm
Processortrådar:	2
Processorlitografi:	32 nm
Värmeavledningseffekt (TDP):	17 W
PCI Express-kortplatser version:	2.0
PCI Express konfigurationer:	1x8, 1x16, 2x4, 2x8
Grafikadapterfamilj:	Intel
Ombord grafikkort modell:	Intel® HD Graphics
Ombord grafikkort:	Ja
Uttag för mikrofon/linje in:	Ja
Intel® Turbo Boost Technology:	Nej
Förstärkt Intel Speedstep Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Nej
Intel® Quick Sync Video Technology:	Nej
Intel® Flex minnesåtkomst:	Ja
Intel® VT-x med utökad Sida Tabeller (EPT):	Ja
Intel® Efterfrågan Baserad Växla:	Nej
Execute Disable Bit-säkerhet:	Ja
Termiska övervakningsteknik:	Ja
CPU konfiguration (max):	1
Inbäddade alternativ:	Nej
Intel Virtualization Technology (VT-x):	Ja
Intel® Dual Display Kan Teknik:	Ja
Intel® Snabb Memory Access:	Ja
Strömlysdiod:	Ja
Lagringsenhetens gränssnitt:	Serial ATA III
Storlekar som stöds på lagringsenhet:	2.5 "
Kylning typ:	Passiv
Antal strömförsörjningsaggregat:	1
Antal processorer installerade:	1
