For the : DL10J Series

XPC BIOS User Guide

Shuttle®

XPC Installation Guide

No part of this publication may be reproduced, transcribed, stored in a retrieval system,

translated into any language, or transmitted in any form or by any means such as electronic,

mechanical, magnetic, optical, chemical, photocopy, manual, or otherwise, without prior

written permission from Shuttle® Inc.

Other brands and product names used herein are for identification purposes only and may

be trademarks of their respective owners.

Disclaimer

Shuttle® Inc. shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

Shuttle® Inc. makes no representation or warranty regarding the contents of this ma-

nual. Information in this manual had been carefully checked for accuracy;however, no

guarantee is given as to the correctness of the contents. For continuing product improve-

ment, Shuttle® Inc. reserves the right to revise the manual or make changes to the speci-

fications of this product at any time without notice and obligation to any person or entity

regarding such change. The information contained in this manual is provided for general

use by customers.

This device complies to Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

1. This device may not cause harmful interference.

2. This device must withstand any background interference including those that may

cause undesired operation.

Trademarks

Shuttle is a registered trademark of Shuttle Inc.

Intel and Pentium are registered trademarks of Intel Corporation.

PS/2 is a registered trademark of IBM Corporation.

AWARD is a registered trademark of Award Software Inc.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

General Notice

Other brand and product names used herein are for identification purposes only and

may be trademarks of their respective owners.

Safety Information

Read the following precautions before setting up a Shuttle XPC.

Installation Notices

Do not place this device underneath heavy loads or in an

unstable position.

Do not expose this device to high levels of direct sunlight,

high-humidity or wet conditions.

Do not use or expose this device around magnetic elds

as magnetic interference may affect the performance of the

device.

Do not block the air vents to

this device or impede the airow

in any way.

CAUTION

Incorrectly replacing the battery may damage this computer. Replace only

with the same or equivalent as recommended by Shuttle. Disposal of used

batteries according to the manufacturer's instructions.

Produktspecifikationer

Varumärke:	Shuttle
Kategori:	Inte kategoriserad
Modell:	XPC slim DL10J
Produkttyp:	Mini-PC, barebone
Vikt:	1300 g
Bredd:	190 mm
Djup:	165 mm
Höjd:	43 mm
Strömförsörjning:	40 W
LED-indikatorer:	HDD, Power
Processorfrekvens:	2 GHz
Processorfamilj:	Intel® Celeron®
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Snabbstartsguide:	Ja
Ursprungsland:	Kina
Antal HDMI-portar:	1
Hörlursutgångar:	1
Certifiering:	FCC, CE, BSMI, RCM, VCCI, RED, RoHS, ErP
HDMI-version:	1.4b
Processor:	J4005
Maximalt internminne:	8 GB
Intel® Smart Response Technology:	Nej
Intel® Hyper Threading Technology (Intel® HT Technology):	Nej
Intel® AES nya instruktioner (Intel® AES-NI):	Ja
Idle stater:	Ja
Intel® Secure Key:	Ja
Intel® 64:	Ja
Intel® OS Guard:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Identity Protection Technology (Intel® IPT):	Ja
Kompatibla operativsystem:	Windows 10 (64-bit)\nLinux
Säkerhet:	CB, BSMI, ETL
Antal lagringsenheter som stöds:	1
Minnestyper som stöds:	DDR4-SDRAM
Typer av lagringsenheter som stöds:	HDD & SSD
Antal minnesplatser:	2
BIOS-typ:	UEFI AMI
Typ av minneskort:	SD
Produktens färg:	Svart
Antal displayportar:	1
VESA-fäste:	Ja
Vikt inkl. förpackning:	2100 g
Inbyggd kortläsare:	Ja
processortillverkare:	Intel
Inbyggd processor:	Ja
Installerat operativsystem:	Nej
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 40 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
processorsockel:	BGA 1090
Processorns kodnamn:	Gemini Lake
Seriella portar:	2
Hållbarhetscertifiering:	ENERGY STAR
AC-inspänning:	100 - 240 V
Material, hölje:	Stål
Nätverksansluten (Ethernet):	Ja
Likströmsingång:	Ja
Växelström Frekvens:	50 - 60 hz
AC-adapter inkluderad:	Ja
Strömkabel ingår:	Ja
Antal USB 2.0 anslutningar:	4
Minnesplatser, typ:	SO-DIMM
Minneskanaler:	Dubbla kanaler
Minnets hastigheter:	2400 MHz
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	2
LAN-styrenhet:	Intel® I211
Moderkortets chipset:	Intel® SoC
Processorkärnor:	2
Processorboostfrekvens:	2.7 GHz
Harmonized System (HS)-kod:	84733080
Produktvikt (oz):	Ja
Typ av kabellåsanslutning:	Kensington
Nätaggregatstyp:	Extern nätadapter
AC-adapter, nätspänning:	19 V
AC-adapter, maxbelastning:	2.1 A
Kvalitet på VGA (D-Sub) porten:	1
Processortrådar:	2
Processorlitografi:	14 nm
Värmeavledningseffekt (TDP):	10 W
PCI Express-kortplatser version:	2.0
PCI Express konfigurationer:	1x2, 1x2+2x1, 1x4, 2x1, 4x1
Grafikadapterfamilj:	Intel
Ombord grafikkort modell:	Intel® UHD Graphics 600
Ombord grafikkort:	Ja
Uttag för mikrofon/linje in:	Ja
Intel® Stöldskydd Teknik (Intel® AT):	Nej
Intel® Turbo Boost Technology:	Nej
Förstärkt Intel Speedstep Technology:	Ja
Intel® Quick Sync Video Technology:	Ja
Intel® VT-x med utökad Sida Tabeller (EPT):	Ja
Execute Disable Bit-säkerhet:	Ja
Termiska övervakningsteknik:	Ja
CPU konfiguration (max):	1
Inbäddade alternativ:	Nej
Intel Virtualization Technology (VT-x):	Ja
ARK-ID för processor:	128992
Lagringsenhetens gränssnitt:	Serial ATA III
Storlekar som stöds på lagringsenhet:	2.5 "
Drivrutiner medföljer:	Ja
Kylning typ:	Passiv
SSD-diskens formfaktor:	2.5"
