Sida 1/25

For the : XC60J Series

XPC BIOS User Guide

Shuttle®

XPC Installation Guide

No part of this publication may be reproduced, transcribed, stored in a retrieval system,

translated into any language, or transmitted in any form or by any means such as electronic,

mechanical, magnetic, optical, chemical, photocopy, manual, or otherwise, without prior

written permission from Shuttle® Inc.

Other brands and product names used herein are for identification purposes only and may

be trademarks of their respective owners.

Disclaimer

Shuttle® Inc. shall not be liable for any incidental or consequential damages resulting from

the performance or use of this product.

Shuttle® Inc. makes no representation or warranty regarding the contents of this ma-

nual. Information in this manual had been carefully checked for accuracy;however, no

guarantee is given as to the correctness of the contents. For continuing product improve-

ment, Shuttle® Inc. reserves the right to revise the manual or make changes to the speci-

fications of this product at any time without notice and obligation to any person or entity

regarding such change. The information contained in this manual is provided for general

use by customers.

This device complies to Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

1. This device may not cause harmful interference.

2. This device must withstand any background interference including those that may

cause undesired operation.

Trademarks

Shuttle is a registered trademark of Shuttle Inc.

Intel and Pentium are registered trademarks of Intel Corporation.

PS/2 is a registered trademark of IBM Corporation.

AWARD is a registered trademark of Award Software Inc.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

General Notice

Other brand and product names used herein are for identification purposes only and

may be trademarks of their respective owners.

CAUTION

Incorrectly replacing the battery may damage this computer. Replace only

with the same or equivalent as recommended by Shuttle. Disposal of used

batteries according to the manufacturer's instructions.

Safety Information

Read the following precautions before setting up.

Installation Notices

Do not place this device underneath heavy loads or in an

unstable position.

Do not expose this device to high levels of direct sunlight,

high-humidity or wet conditions.

Do not use or expose this device around magnetic

elds as magnetic interference may affect the

performance of the device.

Do not block the air vents to this device or impede

the airow in any way.

Produktspecifikationer

Varumärke:	Shuttle
Kategori:	Inte kategoriserad
Modell:	XPC XC60J
Produkttyp:	Barebone-dator
Bredd:	238 mm
Djup:	200 mm
Höjd:	72 mm
Strömförsörjning:	65 W
LED-indikatorer:	HDD, Power
Processorfrekvens:	2 GHz
Processorfamilj:	Intel® Celeron®
Wi-Fi:	Nej
Ljudsystem:	HD
Snabbstartsguide:	Ja
Antal HDMI-portar:	1
Hörlursutgångar:	1
Certifiering:	FCC, CE, BSMI, RCM, VCCI, R&TTE, RoHS, ErP
Processor:	J3355
Intel® Wireless Display (Intel® WiDi):	Nej
Maximalt internminne:	8 GB
Intel® Smart Response Technology:	Nej
Intel® Hyper Threading Technology (Intel® HT Technology):	Nej
Intel® InTru™ 3D-teknik:	Nej
Intel® Insider™:	Nej
Intel® AES nya instruktioner (Intel® AES-NI):	Ja
Idle stater:	Ja
Intel® Small Business Advantage (Intel® SBA):	Nej
Intel® Secure Key:	Ja
Intel® 64:	Ja
Intel® OS Guard:	Nej
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Identity Protection Technology (Intel® IPT):	Ja
Intel® Trusted Execution Technology:	Nej
Intel® Stable Image Platform Program (SIPP):	Nej
Kompatibla operativsystem:	- Windows 10 64-bit\n- Linux 64-bit
Säkerhet:	CB, BSMI, ETL, CCC
Intel® Rapid Storage Technology:	Nej
Minnesspänning:	1.35 V
Antal processorer som stöds:	1
Antal lagringsenheter som stöds:	1
Minnestyper som stöds:	DDR3L-SDRAM
Typer av lagringsenheter som stöds:	HDD & SSD
Antal minnesplatser:	2
BIOS-typ:	UEFI AMI
Produktens färg:	Svart
Inbyggd kortläsare:	Nej
processortillverkare:	Intel
Inbyggd processor:	Ja
Installerat operativsystem:	Nej
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 40 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
processorsockel:	BGA 1296
Processorns kodnamn:	Apollo Lake
Seriella portar:	8
Hållbarhetscertifiering:	ENERGY STAR
AC-inspänning:	100 - 240 V
Nätverksansluten (Ethernet):	Ja
Likströmsingång:	Ja
Växelström Frekvens:	50 - 60 hz
AC-adapter inkluderad:	Ja
Strömkabel ingår:	Ja
Intel Clear Video Technology:	Ja
Antal USB 2.0 anslutningar:	4
Minnesplatser, typ:	SO-DIMM
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	2
LAN-styrenhet:	Intel® I211
Moderkortets chipset:	Intel® SoC
Processorkärnor:	2
Processorboostfrekvens:	2.5 GHz
Produktvikt (oz):	Ja
Typ av kabellåsanslutning:	Kensington
Nätaggregatstyp:	Extern nätadapter
AC-adapter, nätspänning:	19 V
AC-adapter, maxbelastning:	3.42 A
Kvalitet på VGA (D-Sub) porten:	1
Processortrådar:	2
Processorlitografi:	14 nm
Värmeavledningseffekt (TDP):	10 W
PCI Express-kortplatser version:	2.0
PCI Express konfigurationer:	1x2+2x1, 4x1
Grafikadapterfamilj:	Intel
Ombord grafikkort modell:	Intel® HD Graphics 500
Ombord grafikkort:	Ja
Uttag för mikrofon/linje in:	Ja
Intel® Stöldskydd Teknik (Intel® AT):	Nej
Intel® Turbo Boost Technology:	Nej
Förstärkt Intel Speedstep Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® Quick Sync Video Technology:	Ja
Intel® VT-x med utökad Sida Tabeller (EPT):	Ja
Execute Disable Bit-säkerhet:	Ja
Termiska övervakningsteknik:	Ja
CPU konfiguration (max):	1
Inbäddade alternativ:	Ja
Intel Virtualization Technology (VT-x):	Ja
Lagringsenhetens gränssnitt:	Serial ATA III
Storlekar som stöds på lagringsenhet:	2.5, 3.5 "
Drivrutiner medföljer:	Ja
Kylning typ:	Passiv
ECC:	Nej
Chassityp:	3L storlek PC
Antal strömförsörjningsaggregat:	1
PCI Express x4 (Gen 2.x)-kortplatser:	1
Intel® Smart Connect Technology:	Nej
Intel HD Audio-teknik:	Ja
