BIOS User Guide

For the :

NC03U

Shuttle®

Installation Guide

No part of this publication may be reproduced, transcribed, stored in a retrieval sys-

tem, translated into any language, or transmitted in any form or by any means such as

electronic, mechanical, magnetic, optical, chemical, photocopy, manual, or otherwise,

without prior written permission from us.

Other brands and product names used herein are for identification purposes only and

may be trademarks of their respective owners.

Disclaimer

We shall not be liable for any incidental or consequential damages resulting from the

performance or use of this product.

We make no representation or warranty regarding the contents of this ma-

nual. Information in this manual had been carefully checked for accuracy;however, no

guarantee is given as to the correctness of the contents. For continuing product improve-

ment, we reserve the right to revise the manual or make changes to the specifications of

this product at any time without notice and obligation to any person or entity regarding

such change. The information contained in this manual is provided for general use by

customers.

This device complies to Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

1. This device may not cause harmful interference.

2. This device must withstand any background interference including those that may

cause undesired operation.

Trademarks

Intel and Pentium are registered trademarks of Intel Corporation.

PS/2 is a registered trademark of IBM Corporation.

AWARD is a registered trademark of Award Software Inc.

Microsoft and Windows are registered trademarks of Microsoft Corporation.

General Notice

Other brand and product names used herein are for identification purposes only and

may be trademarks of their respective owners.

Safety Information

Read the following precautions before setting up.

Installation Notices

Do not place this device underneath heavy loads or in an

unstable position.

Do not expose this device to high levels of direct sunlight,

high-humidity or wet conditions.

Do not use or expose this device around magnetic

elds as magnetic interference may affect the

performance of the device.

Do not block the air vents to this device or impede

the airow in any way.

CAUTION

Incorrectly replacing the battery may damage this co-mputer. Replace

only with the same or equivalent type recommended by the manufacturer.

Disposal of used batteries according to the manufacturer's instructions.

Produktspecifikationer

Varumärke:	Shuttle
Kategori:	Inte kategoriserad
Modell:	XPC nano NC03U
Produkttyp:	Mini-PC, barebone
Vikt:	400 g
Bredd:	142 mm
Djup:	142 mm
Höjd:	42 mm
Strömförsörjning:	65 W
LED-indikatorer:	Power, Status
Processorfrekvens:	1.8 GHz
Processorfamilj:	Intel® Celeron®
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ljudsystem:	HD
Snabbstartsguide:	Ja
Antal HDMI-portar:	1
Certifiering:	CE, FCC, BSMI, RCM, R&TTE, VCCI, RoHS, ErP
Processor:	3865U
Maximalt internminne:	32 GB
Intel® My WiFi Technology (Intel® MWT):	Ja
Intel® Smart Response Technology:	Ja
Intel® Hyper Threading Technology (Intel® HT Technology):	Nej
Intel® AES nya instruktioner (Intel® AES-NI):	Ja
Idle stater:	Ja
Intel® Secure Key:	Ja
Intel® 64:	Ja
Intel® OS Guard:	Ja
Intel® Virtualization Technology for Directed I/O (VT-d):	Ja
Intel® Trusted Execution Technology:	Nej
Intel® Stable Image Platform Program (SIPP):	Nej
Kompatibla operativsystem:	- Windows 10 64-bit\n- Linux 64-bit
Säkerhet:	CB, BSMI, ETL, CCC
Minnesspänning:	1.2 V
Kompatibla processorer:	Intel Celeron, Intel Pentium
Antal processorer som stöds:	1
Antal lagringsenheter som stöds:	1
Minnestyper som stöds:	DDR4-SDRAM
Typer av lagringsenheter som stöds:	HDD & SSD
Antal minnesplatser:	2
BIOS-typ:	UEFI
Typ av minneskort:	SD, SDHC, SDXC
Produktens färg:	Svart
Antal displayportar:	1
VESA-fäste:	Ja
Vikt inkl. förpackning:	1200 g
Inbyggd kortläsare:	Ja
processortillverkare:	Intel
Inbyggd processor:	Ja
Installerat operativsystem:	Nej
Antal LAN (RJ-45) anslutningar:	1
Temperatur vid drift:	0 - 40 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
processorsockel:	BGA 1356
Processorns kodnamn:	Kaby Lake
Seriella portar:	1
Hållbarhetscertifiering:	ENERGY STAR
AC-inspänning:	100 - 240 V
Material, hölje:	Plast
Nätverksansluten (Ethernet):	Ja
Växelström Frekvens:	50 - 60 hz
AC-adapter inkluderad:	Ja
Strömkabel ingår:	Ja
Intel Clear Video Technology:	Ja
Antal USB 2.0 anslutningar:	2
Minnesplatser, typ:	SO-DIMM
Minneskanaler:	Dubbla kanaler
Minnets hastigheter:	2133 MHz
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	1
Antal USB 3.2 Gen 2 (3.1 Gen 2) typ C-portar:	1
Moderkortets chipset:	Intel® SoC
Processorkärnor:	2
Produktvikt (oz):	Ja
Typ av kabellåsanslutning:	Kensington
Nätaggregatstyp:	Extern nätadapter
AC-adapter, nätspänning:	19 V
AC-adapter, maxbelastning:	3.42 A
Gränsssnitt för panelmontering:	75 x 75, 100 x 100 mm
Processortrådar:	2
Processorlitografi:	14 nm
Värmeavledningseffekt (TDP):	15 W
PCI Express-kortplatser version:	2.0
PCI Express konfigurationer:	1x2+2x1, 1x4, 2x2, 4x1
Optisk enhetstyp:	Nej
Grafikadapterfamilj:	Intel
Ombord grafikkort modell:	Intel® HD Graphics 610
Ombord grafikkort:	Ja
Intel® Turbo Boost Technology:	Nej
Förstärkt Intel Speedstep Technology:	Ja
Intel® Clear Video HD Technology (Intel® CVT HD):	Ja
Intel® Quick Sync Video Technology:	Ja
Intel® Flex minnesåtkomst:	Ja
Intel® VT-x med utökad Sida Tabeller (EPT):	Ja
Execute Disable Bit-säkerhet:	Ja
Termiska övervakningsteknik:	Ja
CPU konfiguration (max):	1
Inbäddade alternativ:	Nej
Intel Virtualization Technology (VT-x):	Ja
Lagringsenhetens gränssnitt:	Serial ATA III
Intel® TSX-NI:	Nej
Storlekar som stöds på lagringsenhet:	2.5 "
Drivrutiner medföljer:	Ja
Kylning typ:	Aktiv
ECC:	Nej
Combo hörlurar / mikrofon-port:	Ja
Chassityp:	Nettop
Antal strömförsörjningsaggregat:	1
PCI Express x4 (Gen 2.x)-kortplatser:	1
