WLR-4003

Wireless Gigabit Router N300

(802.11 b/g/n)

User Manual

TABLE OF CONTENTS

1 KEY FEATURES .................................................................................... 4

2 PACKAGE CONTENTS ........................................................................... 5

3 CAUTIONS .......................................................................................... 6

4 PRODUCT LAYOUT ............................................................................... 7

5 SYSTEM REQUIREMENTS .................................................................... 10

6 WLR-4003 PLACEMENT ....................................................................... 10

7 SETUP LAN, WAN .............................................................................. 11

8 PC NETWORK ADAPTER SETUP ............................................................ 12

9 BRINGING UP THE WLR-4003 ............................................................. 16

10 INITIAL SETUP WLR-4003 .................................................................. 16

11 CONFIGURATION WIZARD .................................................................. 25

12 WIRELESS SETTINGS ......................................................................... 27

13 FIREWALL SETTINGS ......................................................................... 39

14 ADVANCED SETTINGS ........................................................................ 45

15 TOOLBOX SETTINGS .......................................................................... 55

16 APPENDIX ........................................................................................ 67

Revision 1.0

Note: All the information contained in this manual was correct at the time of

publication.

However, as our engineers are always updating and improving the product, your

device‟s software may have a slightly different appearance or modified

functionality than presented in this manual.

Introduction

Congratulations on your purchase of the WLR-4003 Wireless Gigabit Router

N300. The WLR-4003 is compliant with 802.11n and up to 6 times faster than

standard 802.11g based routers while still being compatible with 802.11g &

802.11b devices. The WLR-4003 is not only a Wireless Access Point, but also

doubles as a 4-port full-duplex Gigabit switch that connects your wired-

Ethernet devices together at 10/100/1000 Mbps speeds.

At 300 Mbps wireless transmission rate, the Access Point built into the Router

uses advanced MIMO (Multi-Input, Multi-Output) technology to transmit

multiple streams of data in a single wireless channel, giving you seamless

access to multimedia content. The robust RF signal travels farther, eliminates

dead spots and extends the network range. For data protection and privacy,

the WLR-4003 encodes all wireless transmissions with WEP, WPA, or WPA2

encryption.

With the inbuilt DHCP Server & powerful SPI firewall, the WLR-4003 protects

your computers against intruders and most known Internet attacks and also

provides safe VPN pass-through. With the incredible speed and QoS function of

802.11n the WLR-4003 is ideal for media-centric applications like streaming

video, gaming, and VoIP telephony to run multiple media-intense data streams

through the network at the same time, with no degradation in performance.

This product can be used safely in the countries listed below:

This product complies with the following European Union regulations:
