Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support

Manual Revision: September 9, 2024

Product ID

1G-NETWORK-ISOLATOR

Front View

Bottom View

Rear View

1-Port Gigabit Galvanic Network Isolator

Port/ConnectorFunction

1RJ45 Port 1

• Connect an RJ45Ethernet Cable

• Supported speeds: 1Gbps, 100Mbps, and 10Mbps

• The port is bidirectional

2

DIN Rail

Mounting Point

• Use to secure the included DIN Rail Mounting Kit

3Guide Peg

• Helps to install the in one specic DIN Rail Mounting Kit

orientation

4RJ45 Port 2

• Connect an RJ45Ethernet Cable

• Supported speeds: 1Gbps, 100Mbps, and 10Mbps

• The port is bidirectional

Package Contents

• Network Isolator x 1

• Adhesive Strip x 1

• DIN Rail Mounting Kit x 1

• Quick-Start Guide x 1

Requirements

For the latest manuals, product information, technical specications, and declarations of

conformance, please visit:www.StarTech.com/1G-NETWORK-ISOLATOR

• Phillips head screwdriver

Installation

1. Connect the network to one of the of the InputRJ45Ethernet CableRJ45 Ports

Network Isolator.

2. Use an to connect theremaining on the RJ45Ethernet Cable RJ45 PortNetwork

IsolatorRJ45 PortNetworked Device to an of the .

DIN Rail Mounting (optional)

1. Use the at the bottom of the to align the Guide PegNetwork Isolator

DIN Rail Mounting Kit Phillips Head Screwdriveinto it’s correct position. Use a r to

install th and secure the . (Figure 1) e Self-Tapping ScrewDIN Rail Mounting Kit

*Product may vary from image

1

2

3

4
