HDMI Signal Booster - 115 ft - 1080p

StarTech ID: HDBOOST

This HDMI signal booster lets you increase the signal strength of your HDMI video source so you can connect

an HDMI display up to 115 ft. (35 m) away, using standard HDMI cables. You can place the booster inline

between two HDMI cables, up to 82 ft. in length at the video input, and up to 33 ft. in length at the video output.

Discreet installation

With its small form factor, the HDMI booster is easy to hide, for a discreet installation. You don’t need an

external power adapter to operate the signal booster, and it includes mounting hardware, so installing it is

hassle-free. By extending your video signal using standard HDMI cables, the HDMI booster is a cost-effective

alternative to more expensive HDMI extension systems that require the installation of CAT5 or CAT6 cabling

infrastructure.

Compatible with varying distances

The HDMI booster features an equalization switch with ten different levels. The equalization switch lets you

adjust the amplification of your HDMI signal based on the distance of your cables, so that you can ensure your

HDMI signal will be perfect even at distances up to 115 ft. (35 m). The booster is perfect for boardrooms, offices

or classrooms that may require varying distances depending on the room size.

Maintains high-definition video signals

When extending HDMI over long distances using standard video cabling, higher resolutions can become

www.startech.com

1 800 265 1844

unavailable. Using the HDMI signal booster ensures that you’ll still be able to depend on high-

definition resolutions up to 1080p at 60Hz.

The HDBOOST is backed by a 2-year StarTech.com warranty and free lifetime technical support.

Applications

Avoid running network cabling to extend video signals, by using this booster with standard HDMI cabling

Boost the signal strength of your HDMI video signals for classroom, office or boardroom displays

Features

Discreet installation with a small form factor and no external power adapter

Works at varying distances up to 115 ft. with a built-in equalization switch

Maintain high-definition resolutions up to 1080p

Supports 7.1 surround sound audio

Mounting hardware included

www.startech.com

1 800 265 1844

Technical Specifications

Warranty 2 Years

Audio Yes

Cabling HDMI

Rack-Mountable Yes

Audio Specifications 7.1 surround Sound

Max Distance 35 m / 115 ft

Maximum Cable Length 114.8 ft [35 m]

Maximum Digital

Resolutions

1920 x 1080 at 60Hz

Supported Resolutions 1920 x 1080, 1680 x 1050, 1600 x 900, 1440 x 900, 1360 x 768, 1280 x 800, 1280 x

768, 1280 × 720

Wide Screen Supported Yes

Connector A 1 - HDMI (19 pin) Female Input

Connector B 1 - HDMI (19 pin) Female Output

System and Cable

Requirements

Note: The cable on the from your video source must be longer or equal to the cable on

the display side of the booster.

LED Indicators 1 - power LED (red)

Humidity 5% to 90%

Operating Temperature 0°C to 70°C (32°F to 158°F)

Storage Temperature -10°C to 80°C (14°F to 176°F)

Shipping (Package)

Weight

0.1 lb [0.1 kg]

Included in Package 1 - HDMI signal booster

Included in Package 2 - mounting brackets

Included in Package 4 - mounting screws

www.startech.com

1 800 265 1844

Produktspecifikationer

Varumärke:	StarTech.com
Kategori:	AV extender
Modell:	HDBOOST
Vikt:	72 g
Höjd:	33 mm
Förpackningens bredd:	173 mm
LED-indikatorer:	Energiljus
Videolägen som stöds:	720p, 1080p
Maximal upplösning:	1920 x 1080 pixlar
Ljudsystem:	Flerkanalig
Certifiering:	CE, FCC
Grafikupplösningar som stöds:	1280 x 720 (HD 720),1280 x 768 (WXGA),1280 x 800 (WXGA),1360 x 768 (WXGA),1440 x 900,1600 x 900,1680 x 1050 (WSXGA+)
Modell:	Repeater för AV-utrustning
Uteffekt:	1 A
Rackmontering:	Ja
Ljudutgångskanaler:	7.1 kanaler
Monteringsfästen ingår:	Ja
Antal HDMI-utgångar:	1
Driftspänning:	5 V
Produktens färg:	Svart
Låddjup:	144 mm
Vikt inkl. förpackning:	163 g
Typ av strömkontakt:	Typ N
Produktstorlek (BxDxH):	42.2 x 54.2 x 26.2 mm
Temperatur vid drift:	0 - 70 ° C
Temperaturintervall (förvaring):	-10 - 80 ° C
Intervall för relativ operativ luftfuktighet:	5 - 90 %
Hållbarhetscertifiering:	RoHS
AC-inspänning:	100-240 V
Likströmsingång:	Ja
Harmonized System (HS)-kod:	85176200
Maximal överföringshastighet avstånd:	35 m
Förpackningsstorlek (B x D x H):	143 x 168 x 63 mm
HDMI-in:	1
Stöd för ljud:	Ja
