Sida 1/6

TEG1118P-16-250W

16GE+2SFP Ethernet Switch With 16-Port PoE

www.tendacn.com

TE 1118P-16-250WG

16GE+2SFP Ethernet Switch With 16-Port PoE

Products Description

TEG1118P-16-250W is a unmanaged PoE switch independently designed by Tenda. Compliant with IEEE 802.3af and

IEEE 802.3at standards, it can identify PoE-powered devices intelligently. With a maximum PoE power output of 230W, and

30W for a single port, it can supply power when transmitting data with APs, IP cameras, and IP phones. The switch

supports 4 working modes, including standard, priority, extend and VLAN modes, is an ideal choice for SMBs, hotels,

schools, factories with video surveillance and wireless networking requirements.

01 1 2 FP t ernet itc it 1 Port Po6GE+ S E h Sw h W h 6- E

02 1 2 FP t ernet itc it 1 Port Po6GE+ S E h Sw h W h 6- E

 Compliant with IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE802.3x and

IEEE802.3af/at standards.

 16 * 100/1000 Mbps Base-T RJ45 ports for data transmission and power supply,

2* 1000 Mbps Base-X SFP slot.

 8 K MAC address table and MAC address auto-learning.

 IEEE 802.3x-compliant full-duplex flow control and half-duplex backpressure flow control.

 36 Gbps backplane bandwidth.

 Maximum power consumption of a single port: 30W; Maximum power consumption of the

switch: 250W.

 4 modes: standard, priority, extend and VLAN.

6 kV lightning protection

The switch offers various safety and protection types, including 6 kV lightening protection,

PSE short-circuit protection, PoE overload protection, surge current protection etc.

Gigabit uplink port

With two 1000 Mbps SFP slot, the switch can meet the current demand for uplink

bandwidth of Gigabit WLAN and HD digital surveillance.

230 W PoE power supply

The switch features 16 IEEE 802.3at/af-compliant RJ45 ports. The entire switch offers a

maximum PoE power output of 230 W, and 30 W for a single port, to supply power to and

data transmission with 16 PoE-powered devices such as APs and IP cameras.

Key Feature

Product Features

One-Key to switch 4 modes

It supports 4 working modes, including standard, priority, extend and VLAN modes. The

hardware DIP mode switch makes networking straightforward and effortless.

AF / AT

6KV

Produktspecifikationer

Varumärke:	Tenda
Kategori:	brytare
Modell:	TEG1118P-16-250W
Bredd:	440 mm
Djup:	178.8 mm
Höjd:	44 mm
LED-indikatorer:	Link, PoE, Power
Certifiering:	FCC, CE, RoHS
Rackmontering:	Ja
Kabeltyper som stöds:	Cat5, Cat5e
Produktens färg:	Brun
Monteringsbar på väggen:	Ja
Formfaktor:	1U
Datahastighet för Ethernet-LAN:	100,1000 Mbit/s
Strömförsörjning via Ethernet (PoE) stöd:	Ja
Total Power over Ethernet (PoE)-budget:	230 W
Power over Ethernet (PoE)-effekt per port:	15.4 W
Temperatur vid drift:	0 - 45 ° C
Temperaturintervall (förvaring):	-40 - 70 ° C
Intervall för relativ operativ luftfuktighet:	10 - 90 %
Fuktighet (förvaring):	5 - 90 %
AC-inspänning:	100 - 240 V
Växelström Frekvens:	50 - 60 hz
Kommunikationsstandarder:	IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Adresstabellstorlek:	8000 poster
Switch kapacitet:	36 Gbit/s
Hastighet vid vidarebefordran:	26.8 Mpps
10G stöd:	Nej
Antal SFP+-modulplatser:	1
Antal grundläggande RJ-45 Ethernet-portar:	16
Typ av grundläggande RJ-45 Ethernet-portar:	Gigabit Ethernet (10/100/1000)
Antal fläktar:	1 fläkt/-ar
Switch typ:	Ohanterad
Lagra-och-vidarebefordra:	Ja
Koppar Ethernet-kablar teknik:	1000BASE-T
Fläktlös:	Nej
